aluminum alloy elevator
aluminum alloy aerial lift
Hydraulic mobile single mast aluminum alloy lift platform powered by DC/AC
outdoor aerial working essential ladder lifting platform offer a safe, quick and
easy method of reaching overhead areas. Mostly designed to lift one person,
these platforms are extremely compact, lightweight and easy to maneuver.
The vertical personnel lift consists of a working platform attached to an
aluminium mast that extends vertically, which in turn is mounted on a steel base.
These personnel lifts has a reach of up to 16m and capacities up to 200kg.
aluminum alloy aerial lift : features
You can control the lift both on the platform and ground, just need press
stop button, it can stop at any point if you need.
Personnel Lifts are available in various AC and DC powered models.
aluminum alloy aerial lift :advantages
AC Powered Models (220v)
- Powered by a plugged power point
- No noise and air pollution
- Indoor Usage
- Longer usage time
DC Powered Models
- Battery operated, can be use outdoor
- Use for workspace constraints
1)Adopting high strength aluminum molding material keeps deflecting degree and swing tiny.
2)Equipped with overload safety protection device
3) Equipped with safeguard valve to avoid hydraulic pipe rupture
4)It installs the emergency manual hydraulic valve to cope with power cut.
5)It also can add stretch platform to extend to the desired place when the platform length isn’t enough.
6)Double chains greatly improve the safety factor.
7)Adopt emergency stop button multiple safety protection measures.
8)The translatable supporting legs can ensure working dead zone minimization .
9)Tailor-made guide wheel device equipped on the mast makes lifting smooth and stable.
aluminum alloy aerial lift : type
Model |
Lifting height |
Working height |
Loading Capacity |
Table Size |
Overall Dimensions |
Weight |
Power |
|
(m) |
(m) |
(kg) |
(mm) |
(mm) |
(kg) |
(kw) |
||
Single mast |
||||||||
HTLH4-125-1 |
4 |
5.7 |
125 |
600*550
|
1300*800*1620 |
220 |
0.75 |
|
HTLH5-125-1 |
5 |
6.7 |
1300*800*1620 |
260 |
||||
HTLH6-125-1 |
6 |
7.7 |
1300*800*1620 |
270 |
||||
HTLH8-125-1 |
8 |
9.7 |
1375*830*1980 |
320 |
||||
HTLH10-125-1 |
10 |
11.7 |
100 |
1400*900*1980 |
350 |
|||
Double masts | ||||||||
HTLH6-200-2 |
6 |
7.7 |
200 |
1190*540 |
1450*890*1980 |
420 |
1.5 |
|
HTLH7-200-2 |
7 |
8.7 |
1190*540 |
1450*890*1980 |
480 |
|||
HTLH8-200-2 |
8 |
9.7 |
1200*600 |
1450*890*1980 |
520 |
|||
HTLH10-200-2 |
10 |
11.7 |
1400*600 |
1550*890*1980 |
550 |
|||
HTLH12-200-2 |
12 |
13.7 |
1500*600 |
1700*920*1980 |
640 |
|||
HTLH14-200-2 |
14 |
15.7 |
1550*600 |
1750*950*2300 |
720 |
|||
Triple masts | ||||||||
HTLH10-200-3 |
10 |
11.7 |
200 |
1300*540 |
1550*900*1980 |
720 |
1.5 |
|
HTLH12-200-3 |
12 |
13.7 |
1450*540 |
1700*890*1980 |
780 |
|||
HTLH14-200-3 |
14 |
15.7 |
1600*880 |
1800*1200*2480 |
980 |
2.2 |
||
HTLH16-200-3 |
16 |
17.7 |
1780*800 |
1800*1200*2580 |
1180 |
|||
Tiltable triple masts |
16( M )3100*1200*2000(put down) 18( M )3200*1200*2200(put down) |
|||||||
Four masts | ||||||||
HTLH14-200-4 |
14 |
15.7 |
200 |
1600*800 |
1800*1000*2420 |
1000 |
2.2 |
|
HTLH15-200-4 |
15 |
16.7 |
1700*800 |
2000*1000*2630 |
1200 |
|||
HTLH16-200-4 |
16 |
17.7 |
1700*800 |
2000*1000*2650 |
1300 |
|||
HTLH18-200-4 |
18 |
19.7 |
1700*500 |
2100*1000*2800 |
1400 |
|||
Tiltable four masts |
16( M )3300*1200*2000(put down) 18( M )3200*1200*2200(put down) 20( M )3650*1200*2200(put down) |
|||||||
packaging: standard international packaging . The wooden case can be customized as the machine size. Water-proof.
shipping: The loading port is Qingdao,China. We will delivery your machine once your order done within 15 days.
