Specifications
1.API slotted casing pipe2.High quality with competitive price
3.Good Filtering performance
4.Advance process equipment
API 5CT Slotted Casing Tube
Material: J55, K55, N80, L80, P110, etc
Character: Oil filter screen pipe/slotted oil sieve tubes are used for oil exploring.The rigid construction and high quality of materials make possible a product that lasts longer and requires less maintenance. We also can offer galvanized ones to prolong the operational life.
Features:
1.A continuous slot opening which significantly increases the available open area, thus providing greater access to the water bearing zone.
2.Filter area is big,flow resistance is small,high producing oil rate
A uniform and efficient well development due to the continuous slot opening
3.Our product have good character of anti-acid,anti-alkali and anti-corrosion,it can adapt to the oil well’s special demand. the crack won’t become bigger because of corrosion.it has good stability
4.They have the features of easy backwashing,durable in use,safety and reliability as well as low comprehensive cost.
Specification:
continuous slot screen,pipe base screen,perforated tube,slotted pipe, sieve strainer,gas strainer,casing pipe
length:≤12m (each)
outside diameter :50-500mm
thread: BTC,LTC,STC
slot width:(0.10-4)mm±0.03mm
slot number:as per customer's requirement
slot shapes:straight in line pattern, staggered pattern ,spiral pattern
slot space:as per customer's requirement
slotted casing with apertures of 0.20-6mm are wide used in prevention of oil and wells
