CNC spring making machine, High speed automatic machine

Specifications

1) Cheap CNC spring making machine;
2) Used to make wire molding etc;
3) High speed automatic CNC spring making machine.

GH-CNC10A CNC spring making machine

1. No cam, no rocker, no need to install the cam plate. The mechanical parts are specially designed for various ultra-precision springs with the up-to-date design philosophy.

2. The sliding house is designed with full rolling guide track without rocker. Safety device is equipped to avoid a collision between machine and cutting tools.

3. With the operation habit of universal machine, it is added with more functions. It supports on-line programming and it is easy to operate.CNC spring making machine

4. The update program is available from the internet. It supports hand wheel and testing knob control trial processing.High speed CNC spring machine.

5. The location of cam and rotation core can be set by means of the parameters, which still exist after shutdown. High-sensibility probe control, angle control±2°. It can be used to manufacture various ultra-precision irregular springs, compression springs, tension springs, dual-torsion spring, flat wire (spiral power spring) and wire molding spring etc.



Model GH-CNC10A Axis 10 AxisCNC spring making machine

 Diameter 0.08~0.3mm Max Feeding Dia 100mm

Max Feeding Length unlimited

Max production speed 100RPM

Probe 4set Cam Servo Motor 5.5kw

Wire Feed Servo Motor 7.0kw Axis

Servo Motor 1.5kw Coiling Axis 400w

Power AC single-phase 220V

Dimension 1200 X 520 X 1750mm

Weight 350kg
