Home > Industrial Equipment & Components > Pump & Vacuum Equipment > Water Pump > Stainless Steel Shaft High Flow Rate Piping Pump IL40-125 0.8hp 1hp 1.5hp

Stainless Steel Shaft High Flow Rate Piping Pump IL40-125 0.8hp 1hp 1.5hp

Name: Stainless Steel Shaft High Flow Rate Piping Pump IL40-125 0.8hp 1hp 1.5hp
Brand: WONDER
SKU: 107843115
Availability: InStock

Stainless Steel Shaft High Flow Rate Piping Pump IL40-125 0.8hp 1hp 1.5hp thumbnail-1

Stainless Steel Shaft High Flow Rate Piping Pump IL40-125 0.8hp 1hp 1.5hp photo-1

US$ 130 - 260 MOQ: 50 Sets

Key Specifications

Get Latest Price

Place of Origin:

Fujian, China

Brand Name:

WONDER

Model Number:

Pipingpump IL40-125

Contact Supplier Request Quote Chat Now

Fujian Wonder Electric Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Fuzhou

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Fujian, China

Brand Name WONDER

Model Number Pipingpump IL40-125

Theory Centrifugal Pump

Structure Single-stage Pump

Usage Water

Power Other, 1hp-2hp

Standard or Nonstandard Standard

Fuel Other, electric

Pressure High Pressure

Application Submersible

stainless steel shaft high flow rate piping pump IL40-125 0.8hp 1hp 1.5hp

Product Description

CHRACTERISTICS

Flow rate up to 350 L / min.

Head up to 19 m.

Suction lift up to 8m.

Impeller : S.S.304.

Mechanical Seal : ceramic and graphite.

Stainless steel shaft and pump boby.

Inlet and outlet : 38.5X38.5 mm.

Electric motor : close-coupled to a carefully matched with Wonder single-phase/three phase motor , quite running , totally enclosed fan cooled (TEFC) , suitable for S1-continuous duty .

Insulation : Class B.

Protection : IP44.

Inline with the motor , designed by maximally reducing axial size , greatly shorten the shaft of the cantilever , ensure the pump shaft concentric and smooth opeation with low noise , little vibration , and with high efficiency.

Transport the corrosive liquid not containing solid particles , and the viscosity similar to water , applicable to use in petrochemical , metallurgy , electric power , paper making , food , pharmacy , and synthetic fiber fields.
