THREE PHASE HIGH EFFICIENCY ASYNCHRONOUS CAST IRON MOTORS
WE series three phase asynchronous motor is complete new designed high efficiency motor with cast iron housing. Its efficiency indicators are in line with IE2 and Australia MEPS2 (Level 1A).
Characteristics for all WONDER standard 3-Phase asynchronous motors
·Widely applied in general machinery and industries such as pumps & water
treatment, road machinery, petroleum, chemical, metallurgy,
cement and paper-milling.
·IP55 protection, Class F insulation, B Temperature rise, S1 duty,
·Rated voltage 400V, Rated frequency 50Hz.
·Operation conditions: ambient temperature:-20℃~40℃, altitude≤1000m.
·Y-connection for motors up to 3kW and -connection for 4kW and above
·Cooling method is Ic411.
MOUNTING ARRANGEMENTS
basic types of construction may be used in all derived types of constructon
(*)not-defined mounting by IEC 60034-7
1) for the types of construction IM V3,IM B6,IM B8 inquiry is necessary.
