Brewhouse Stainless Steel Beer Brite Tank

Specifications

Stainless steel brite tank
1) SUS304 / 316L
2) single-layer / 2-layer / 3-layer
3)mirror polish inside / satin polish outside

Brewhouse Stainless Steel Beer Brite Tank

1. This kind of storage tanks are widely used for storage water / oil / liquid etc.

2. Suitable for such fields as dairy, juice,beverage, medicine chemical or bio-engineering project, etc .

3. We can manufacture according your special requirements.

Features Include:

•     Shadowless Manway
•     Thru the Wall Spray Ball
•     CIP Lines
•     2" Pull Handle Butterfly for Drain with Elbow and 12" Spool to outside wall
•     Thermometer
•     Thermowell
•     Sample Valve
•     3mm Thickness Tanks
•     2 extra 1 1/2" ferules on top for accessories
•     Dimple Jacketed, Insulated Polyurathane Filled ;

 Optional Accessories:

•     Pressure Relief/Vaccumm Valve Available
•    1" Rotating Racking Arm with 1 1/2" TC Butterfly Valve
•     Carbon Stone Available
•     Extra Ferules installed per ferule 1" thru 3" sizes
•     Sight Level Glass with 2 valves Installed;
•     Oval Manway 430mm x 330mm (550mm x 430mm) with Seal on side;

Jacketed Bright Beer Tanks are available from 1 barrel to 100 or more barrels.  The Bright(Brite) tank have the dish cover at top & bottom with the Cylinder Boday.  All tanks are food grade stainless steel 304 with a 3 mm thickness for 3BBL-70BBL, while larger tanks have a 4 mm thickness.  The cooling system is a dimple jacket with insulated polyurathane fill.  All tanks are designed for up to 14.7 PSI and tested at 30 PSI.  The inside of the tanks are polished to Ra>.22um and the outside is a brushed / Satin finish.  All tanks come standard with 25% head space on top of working volume.

Our Bright beer tanks are beautifully designed for the discriminating brewer and loaded with many standard features.  These features provide commercial brewery functionality & consumer good pricefor all brewers alike.  Special orders may be placed along with custom features to your specifications.
