Specifications
Stainless steel brite tank
1) SUS304 / 316L
2) single-layer / 2-layer / 3-layer
3)mirror polish inside / satin polish outside
Beer Brite Tank For Storing Beer
1. This kind of storage tanks are widely used for storage water / oil / liquid etc.
2. Suitable for such fields as dairy, juice,beverage, medicine chemical or bio-engineering project, etc .
3. We can manufacture according your special requirements.
Features Include:
- Shadowless Manway
- Thru the Wall Spray Ball
- CIP Lines
- 2" Pull Handle Butterfly for Drain with Elbow and 12" Spool to outside wall
- Thermometer
- Thermowell
- Sample Valve
- 3mm Thickness Tanks
- 2 extra 1 1/2" ferules on top for accessories
- Dimple Jacketed, Insulated Polyurathane Filled ;
Optional Accessories:
- Pressure Relief/Vaccumm Valve Available
- 1" Rotating Racking Arm with 1 1/2" TC Butterfly Valve
- Carbon Stone Available
- Extra Ferules installed per ferule 1" thru 3" sizes
- Sight Level Glass with 2 valves Installed;
- Oval Manway 430mm x 330mm (550mm x 430mm) with Seal on side;
1) we will supply and confirm you with drawing before manufacturing.
2) we manufacture the equipment according the drawings.
3) we will send the fittings free which has broken at accident during two years.
Jacketed Bright Beer Tanks are available from 1 barrel to 100 or more barrels. The Bright(Brite) tank have the dish cover at top & bottom with the Cylinder Boday. All tanks are food grade stainless steel 304 with a 3 mm thickness for 3BBL-70BBL, while larger tanks have a 4 mm thickness. The cooling system is a dimple jacket with insulated polyurathane fill. All tanks are designed for up to 14.7 PSI and tested at 30 PSI. The inside of the tanks are polished to Ra>.22um and the outside is a brushed / Satin finish. All tanks come standard with 25% head space on top of working volume.
Our Bright beer tanks are beautifully designed for the discriminating brewer and loaded with many standard features. These features provide commercial brewery functionality & consumer good pricefor all brewers alike. Special orders may be placed along with custom features to your specifications.
