Original Fiberhome OLT AN5516-04 GPON/EPON/GEPON 2U MINI OLT
US$ 1,800 - 2,800
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Hubei, China
Brand Name:
Fiberhome, FiberHome
Model Number:
AN5516-04, AN5516-04
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
EMERSON 220V To 48V 30A Power Converter EPS30-4815AF for C300 C320 C220 MA5600T MA560T MA5683T MA5608T AN5516 OLT Power SupplyUS$ 480.00 - 530.00MOQ: 1 Set -
Wholesale 100% Original Brand New ZTE Fiberhome Huawei GPON OLT GEPON OLTUS$ 1,200 - 2,500MOQ: 1 Piece
-
Original Brand New Huawei MA5600T MA5680T MA5683T MA5608T EPON GEPON GPON Huawei OLTUS$ 40 - 75MOQ: 1 Piece
-
Brand New HUAWEI GPBD 8 Ports GPON OLT Interface Board for MA5608T MA5680T MA5683T MA5600TUS$ 350 - 650MOQ: 1 Piece
-
Huawei GPON OLT Fiber Equipment SmartAX MA5800-X7 MA5800-X17US$ 3,300 - 3,600MOQ: 1 Set
Place of Origin
Hubei, China
Brand Name
Fiberhome, FiberHome
Model Number
AN5516-04, AN5516-04
Original Fiberhome OLT AN5516-04 GPON/EPON/GEPON 2U MINI OLT
Product Description
Produced by FiberHome is one of the advanced FTTx OLT equipment. It is a small capacity carrier class GPON/EPON equipment which provides maximum 1024 ONU users at the 1:64 split ratio. AN5516-04 can be configured to compatible GPON/EPON OLT platform. GPON and EPON users can be concurrently supported in the same OLT subrack by using different ONUs but of the same set of ODN facility. AN5516-04 can be also configured as10GEPON or P2P platform.
Standard Fiberhome OLT AN5516-04 OLT configuration:
- 1 AN5516-04 Chassis
- 1 HSUA control board
- 2 PWRD DC Power board (We also selling 110V/220V To 48V)
- 1 GC8B 8Ports GPON baord with 8pcs SFP Module or EC8B 8Ports EPON Board with 8pcs SFP Module
- 1 FAN
- Power cable & Accessories
Key Features:
PON features
- Unify platform for EPON/GPON/10G PON/P2P
- Sharing service cards with AN5116-06B
- Up to 32 PON ports per chassis
- Flexible uplink card :2*10GE+2*GE,1*STM-1, 32*E1
Synchronization features
- High precision sync-Ethernet & 1588v2
- 1PPS+ToD output
Reliability features
- Core card 1+1 redundancy
- OSPF dual homing
- STP/RSTP/MSTP ring protection
- Trunk/LACP for uplink protection
Product Specifications:
| Dimensions (W D H mm) | 480mm270mm88mm |
| Chassis weight (Fully Loaded) | 10kg (Full Loaded) |
| Capacity (Per subrack) | support max 1024 ONU users |
| Capacity (Per service card) | 4/8 PON ports per EPON service card 4/8 PON ports per GPON service card |
| Core Switch Capacity | 488 Gbps |
| Environment Requirement | Operating temperature -10°C~55°C Storage temperature -40°C~65°C Ambient humidity 5%~95% |
| Service | Ethernet service |
| CATV service | |
| NGN voice (MGCP/H.248/SIP) | |
| TDM service | |
| Broadcast services for IPTV | |
| VOD unicast | |
| Uplink Interface | Up to 6×GE optical uplink with SFP |
| Up to 6×GE electrical uplink | |
| PON Port Interface | GPON port complying with Class B+/C for ODN |
| EPON 1000BASE-PX10/PX20 port for ODN | |
| Up to 60km Max Reach | |
| SC/PC Connector | |
| Support G.652/G.657 Single mode Fiber | |
| Wavelength | Wavelength: TX 1490nm(1550nm)/RX 1310nm |
| Optical Line Rate | Upstream/Downstream data rate: 1.244G/2.488G for GPON |
| Upstream/Downstream data rate: 1.25G/1.25G for EPON | |
| Power Consumption (full configured) | 200W (Full Loaded) |
| Power Supply | -48V DC (-40V~-57V)(Two power cards per subrack for redundancy) |
|
220V AC
|
