high speed atm roll slitter machine
USD $1,000 - $10,000
/ Set
1 Set(Min.Order)
- 30 Set / Sets per Month
- NINGBO
- T/T Credit Card
You May Like
- 4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
- Jotun JT-SDJ Industrial Automatic Metal Sheet Surface Polishing Machine
- Large Metal Sheet Metal Workpiece Processing Deburring Chamfering Plane Belt Polishing Machine
- Heavy Duty Automatic Wide Belt Metal Sand Deburring Machine
- Metal Plate Deburring and Rust Removal Machine Steel Plate Sand Belt Drawing and Polishing Equipment Flat Polishing Machine
- Metal Flat Sheet Laser Cutting Parts Deburring Grinding Polishing Machine Manufacturer
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | MINGTAI | Model Number: | MT |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1.printed pe,pp,pvc,pof,pet,bopp2.one year warranty
3.multifunctional
4.high speed
high speed atm roll slitter machine
Main Technical Parameter:
- Slitting Material:Film,Paper Roll etc
- Slitting Width:25-1300mm
- Machine Speed: 180m/min
- Slitting Speed: 160m/min
- Unwinding Diameter: 600mm Tension 50N.m 3” Air shaft
- Rewinding Diameter:2x400mm Tension 50N.m 3” Air shaft
- Main Motor:3KW frequency conversion motor
- Cutting System: Adopt flat blade,slitting accuracy:±0.1mm,minimum slitting width:25mm
- Transmission: Belt
- Guide Roller: 80 Hard Aluminum Alloy
- Machine Construction: Alloy Iron
- Web guide scope:120mm Accuracy:±0.3mm
Configuration:
- Main Control Part:It has the function of meter counting or length counting,automatic stopping, Speed Adjustment.
Unwinding Tension: Adopt Magnetic Powder control tension 50N.M
Rewinding Tension: Adopt Magnetic Powder control tension 50N.M
Main Motor: Adopt Three Phase AC 3KW Frequency Conversion Motor
- Running and Locking:Pneumatic
- Lower Voltage Apparatus:Adopt CHNT
- Pneumatic Component:Adopt Domesitc Mingyou or Jingwei
- Web Guide: Adopt photoelectric eye
- Slitting Blade: Scaleplate Orientation,it’s easy to install,and accurate
Contact Us
- Ruian Mingtai Printing & Packaging Machinery Co., Ltd.
- Contact nameGloria Hwang
- Phone86-577-65166866
- AddressQianbu Industrial Zone, Shencheng Street, Ruian
