SMTSEC SVC-HD610-SE600 Low Cost High Performance 2.0MP HD Video Camera 12x Digital Zoom Lens Video Conference System Camera

SMTSEC SVC-HD610-SE600 Low Cost High Performance 2.0MP HD Video Camera 12x Digital Zoom Lens Video Conference System Camera thumbnail-1
SMTSEC SVC-HD610-SE600 Low Cost High Performance 2.0MP HD Video Camera 12x Digital Zoom Lens Video Conference System Camera thumbnail-2
SMTSEC SVC-HD610-SE600 Low Cost High Performance 2.0MP HD Video Camera 12x Digital Zoom Lens Video Conference System Camera thumbnail-3
SMTSEC SVC-HD610-SE600 Low Cost High Performance 2.0MP HD Video Camera 12x Digital Zoom Lens Video Conference System Camera photo-1
SMTSEC SVC-HD610-SE600 Low Cost High Performance 2.0MP HD Video Camera 12x Digital Zoom Lens Video Conference System Camera photo-2
SMTSEC SVC-HD610-SE600 Low Cost High Performance 2.0MP HD Video Camera 12x Digital Zoom Lens Video Conference System Camera photo-3
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Audio Conference System, Network Conference System, Video Conference System
Function:
Other, video conference camera
Simultaneous Interpretation:
No
Contact Supplier Request Quote Chat Now
Shenzhen Smart Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Audio Conference System, Network Conference System, Video Conference System
Function Other, video conference camera
Simultaneous Interpretation No
Place of Origin Guangdong, China
Brand Name SMTSEC
Model Number SVC-HD610-SE600

SMTSEC SVC-HD610-SE600 Low Cost High Performance 2.0MP HD  Video camera 12x digital zoom lens  Video conference  system camera

Product Description

Low Cost High Performance 3.27 MP HD Video camera achieved 1080p@30 high quality images. Equipped with SONY 3x optical, 12x digital zoom lens with wide HorizontalView field, ideally for small-sized videoconference rooms, auditoriums, and classroom.


Features:

 cutting-edge High Definition PTZ camera

 Fast and smooth video handling

 Low cost design for marketing

 Power ON-OFF switch

 Work & Standby LED indicator

 Speed Match

 Auto/Manual focus/brightness/WB

 RS-232C/VISCA Protocol

 Lens/Dome OSD

 Boundary scanning

 Standby & wakeup status

 Swap video format

 DVI Video output

Performance:

 1/2.8" Type CMOS

 3.27 Megapixel

 0.25 Lux at F1.2

 720P@30, 1080P@30

 3x Optical x 12 digital zoom

 f=3.00to 9mm F1.2-2.1

 HOV 90° degree

 HDMI DVIVideo output

 Pan : 0-355°

 Tilt: Up: 45°, Down: 45°

 64 preset positions

 4 cruise lines

 DC 12V, 2A

Dimension:

 L 250mm x W 140mm x H154mm

 N. Weight: 1.23 kgs (only camera)

 G. Weight: 2.4 kgs (one unit)

 N.W Carton of 2 units: 2.6 kgs

 G. W Carton of 2 units:5.5 kgs

Installation:

 Desktop

 Ceiling mount

 Standard Tripod accessory



Model No.

SVC-HD 610-SE600

Sensor

Image Sensor

1/2.8" Type CMOS

Effective Pix

3.27 Megapixel

Min. Illumination

0.25 Lux at F1.2

White balance

Auto/Manual/Indoor/Outdoor

Gain control

Auto

Backlight compensation

On/Off

Shutter speed

1/5~1/10,000S, 22 steps

S/N ratio

>50db

Lens

Focus

f=3.00(wide) to 9mm(tele) F1.2-2.2

Iris

Auto/Manual

Lens

3x Optical x 12 digital zoom

Horizontal view angle

1080P:90 degree

720P:70 degree

Video output

DVI

Signal system

720P@30, 1080P@30

Control terminal

EIA/RS232C,EIA/RS485(Bidirectional)

Control Protocol

VISCA,PELCO-D

baud rate

9600/38400bps

patrol line

4 cruise sequence

preset position

64 preset positions

Speed Match

Pan/Tilt movement speed depends on camera module zoom in/out

OSD Menu

Access to OSD Menu and adjust camera module parameters

Image auto flp

Support Horizontal/Vertical image flip

Pan movement speed

1-200°/Second

Tilt movement speed

1-150°/Second

Pan movement range

Pan: 0-355°

Tilt movement range

Up: 45°, Down: 45°

Pan scanning automatically

Support Pan scanning automatically

Boundary scanning

0-359°  scanning (programmable)

Remote controller

IR Wireless Remote controller P/T/Z

Power supply

DC12V,2A

Work Temperature

0-50℃

Humidity

0-95%RH

LxWxH

250mm x 140mm x 145mm

Weight

1380g






Packaging & Shipping



China Post (10-30 days)
EMS (5-15 working days)
DHL (3-5 working days)
UPS (3-5 working days)



•The most reliable, affordable way of shipping method deponds on your address.
•Online tracking number will be emailed to buyer through email.
•We dont take any responsibility for any custom delay.



Our Services



•All products have been checked and packaged in good condition before dispatch.

•All products have 1 year warranty.
