PTZ Control Support Mobile Client Built in WIFI Video In/out 3.5" Touch Screen 480X320 CCTV CVI Camera Tester(IPC-5300 CVI)
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SMTSEC
Model Number:
IPC-5300 CVI
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Single Channel CCTV Audio,Video and Power Transmitter and Receiver (SU-B101)NegotiableMOQ: 1 Piece -
Support Mobile Client HDMI Output UTP Cable Tester 4.3" Touch Screen 800X480 WiFi SDI Camera CCTV Tester(IPC-3400 SDI)NegotiableMOQ: 1 Piece
-
140 PCS D5mm45Degree LED CCTV Small Power IR Illuminator 850nm (AC110-220V, DC12V, Optional)(SI-140-45)NegotiableMOQ: 1 Piece
-
2.8~12mm,Aperture F1.4,CS/DC Mount,1/2.7" Format,Angle 90-28 Degree DC Drive 2.0 Mega Pixels Auto Iris Lens(SL-2812AMP)NegotiableMOQ: 1 Piece
-
6~22mm,Aperture F1.4,CS/DC Mount,1/2.7" Format,Angle 55-13 Degree DC Drive 2.0 Mega Pixels Auto Iris Lens(SL-0622AMP)NegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
SMTSEC
Model Number
IPC-5300 CVI
Product Description
PTZ control Support mobile client Built in WIFI Video in/out 3.5" Touch Screen 480X320 CCTV CVI Camera Tester(IPC-5300 CVI)
> 3.5 inch touch screen, 480X320 resolution
> Easy To Operate
> Curves and screenshot storage
> IP camera Analog camera test
> PTZ control,Color bar generator
> IP address scan,PING network test etc
> Support ONVIF Protocol IP camera
> Support mobile client
> Video in/out
> DC12V power output
> Audio input, Color bar generator
> UTP Cable tester, Data Monitor
> Photograph,Video record,And playback
> Network TESTING
> Cable scan,POE tester,WIFI function
> CVI camera Tester
Parameters
| Model | IPC-5300 CVI |
| Tester Type | CCTV CVI Camera Tester |
| Display | 3.5 inch Capacitive touch screen , resolution 4800(RGB)X 320 |
| Network port | 10/100M auto adapt,RJ45 |
| CVI camera test | Support resolution 720p 25fps,30fps,50fps,60fps / 1080P 25fps,30fps , camera OSD menu control over coaXial cable |
| WIFI | Built in WIFI,speeds150M,display wireless camera image |
| IP camera type | ONVIF,ACTi,Dahua IPC-HFW2100P,Hikvision,DS-2CD864-E13,Samsung SNZ-5200,Tiandy TD-NC9200S2,Kodak IPC120L,Honeywell HICC-2300T,Aipu-waton IP5000-BC-13MP/IRS06-13MP,fine-Tida IPC,FSJ BY-1080Q,WEISKY IPC camera etc. Customized welcome |
| Video input/output | 1 channel BNC input & 1 channel BNC looped output, NTSC/PAL (Auto adapt) |
| Video Level Test: | Video signals measured in IRE or mV |
| Zoom Image | Support Analog camera and IP camera image zoom /move |
| Snapshot, | Image Screen snapshot, record ,save ,view and record and play back |
| Video record and playback | |
| 12V/1Apower output | Output DC12V/1A power for camera |
| Audio test | 1 channel audio signal input, test whether sound normal, 1 channel audio signal, to connect headphone |
| PTZ control | Support RS232/RS485 control, Baud 600-115200bps, Compatible with more than 30 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc |
| Video Signal Generator | Output one channel PAL/NTSC color bar video signal for testing monitor or video cable.(red, green ,blue, white and black color ) |
| color bar generator | Local side PC can login the tester, send the signal by network ,test network connection communication whether normal |
| UTP Cable tester | Test UTP cable connection status and display on the screen. Read the number on the screen |
| Data monitor | Captures and analyzes the command data from controlling device,also can send heXadecimal |
| Network test | IP address scan, link test, Ping test, Quickly search the connection IP camera and other device’s IP address |
| PoE test | Measurement POE switch or PSE power supply voltage and cable connection status |
| POWER | |
| EXternal power supply | DC 5V(1.5A ) |
| Battery | Built-in 3.7V Lithium polymer battery ,3000mAh |
| Rechargeable | After charging3~4 hours, normal working time8hours |
| Parameter | |
| Operation setting | Capacitive touch screen, OSD menu,Chinese/English |
| Auto off | 1-30 (mins) |
| General | |
| Working Temperature | -10℃---+50℃ |
| Working Humidity | 30%-90% |
| Dimension/Weight | 194mm X 112mm X 48mm / 540g |
Packaging & Shipping
China Post (10-30 days)
EMS (5-15 working days)
DHL (3-5 working days)
UPS (3-5 working days)
•The most reliable, affordable way of shipping method deponds on your address.
•Online tracking number will be emailed to buyer through email.
•We dont take any responsibility for any custom delay.
Our Services
•All products have been checked and packaged in good condition before dispatch.
•All products have 1 year warranty.
