Description: We can supply all type Flat Yarn Making Machine such as high speed Flat Yarn Making Machine, economic type Flat Yarn Making Machine, PP flat yarn making machine, PE flat yarn making machine.
Our PP Flat Yarn Making Machine and PE Flat Yarn Making Machine can make flat yarn to weave the rice woven bag, jumbo woven bag, FIBC woven bag, bigger woven bag, container bag, cement woven bag, Flour Woven bag, wheat woven bag.
The Flat Yarn Making Machine uses the polypropylene (PP) or polyethylene (PE) material to make tape (flat yarn) through production procedures of material heating & extruding, splitting the film into tapes, the tapes stretching & forming, tapes winding on the bobbins by winding machine, then put the bobbins with tapes on circular loom for weaving.
Through our many times improving, the machine can be fit for all kinds PP&PE material, such as 100% recycled PP & PE, powder or grain PP & PE, to produce the tapes. The screw and barrel of extruder are made of high quality 38CrMoAlA allay steel, the hardness is over HV950 after nitrogenizing treatment. The gears & chain wheels are made of 45# medium carbon steel and done the treatment of high frequency quench. The driving rollers are electroplated with hard Cr, tension self-controlling of winding-rollers are applied to the driving unit. The barrel of extruder, bullhead tee and die adopt cast aluminum heater which is endurable. It has the performance of easy operation & maintenance, reliable quality & running and long usage life.
The PP Flat Yarn Making Machine and PE Flat Yarn Making Machine also can make flat yarn to make rope. |
|
SJPL Series Plastic Extrusion Flat Yarn Production Line is specially designed for PP and HDPE with high quality and excellent performance. Perfect tape quality, Lowest consumption, Best economic benefit.
|
Performance: |
|
|
Application: |
Plastic woven sack, Chemical bag, Foods bag, Rice bag, Sugar Bags, Leno bag, Jumbo bag, FIBC bag, Contain bag, Geo textile, Tarpaulin, Carpet backing tape, Artificial grass tape, etc. |
Main Technical Parameter
Model |
SJPL-Z65/30-700/112 |
SJPL-Z90/33-1000/160 |
SJPL-Z100/30-1200/192 |
SJPL-Z120/30-1500/256 |
Max. extrusion capacity |
180kg/h |
280kg/h |
350kg/h |
490kg/h |
Motor of extruder |
60kw |
90kw |
120kw |
160kw |
Dia. of screw |
65mm |
90mm |
100mm |
120mm |
Ratio of screw L/D |
30:1 |
33:1 |
30:1 |
30:1 |
Revolution of screw |
20∼160r/min |
20∼120r/min |
30∼120r/min |
30∼120r/min |
Width of die |
700mm |
1000mm |
1200mm |
1500mm |
Max. winding speed |
280m/min |
280m/min |
280m/min |
280m/min |
Range of flat yarn fibre |
60∼200tex |
60∼200tex |
60∼200tex |
60∼200tex |
Stretching ratio |
4∼10 |
4∼10 |
4∼10 |
4∼10 |
Number of winder |
112spindles |
160spindles |
192spindles |
256spindles |
System installed capacity |
237kw |
300kw |
320kw |
400kw |
Normal operational capacity |
160kw |
180kw |
190kw |
230kw |
Weight (About) |
20000kg |
27000kg |
30000kg |
32000kg |
Overall dimension (L×W×H) |
26500×3200×2600 |
32000×3200×2600 |
35000×3200×2600 |
39000×3200×2600 |
