DEUTZ Diesel Generator

DEUTZ Diesel Generator thumbnail-1
DEUTZ Diesel Generator photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
DEUTZ
Model Number:
WT-DEUTZ
Contact Supplier Request Quote Chat Now
Fuan Wangwantong Electric Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FUZHOU
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name DEUTZ
Model Number WT-DEUTZ
Output Type AC Three Phase
Speed 1500/1800rpm
Frequency 50/60Hz
Rated Power 24-1600kW
Rated Voltage 220/380V, 230/400V, etc.
Rated Current 43A-2880A

Specifications

DEUTZ Diesel Generator
1. Rated Output: 24-1600KW
2. OEM of DEUTZ
3. CE, ISO9001 approved
4. 12 months warranty

DEUTZ Diesel Generator
1) Rated power: 24KW-1600KW (30KVA-2000KVA)

2)Engine: Deutz

3)Alternator; our brushless alternator, or STAMFORD,LEROY SOMER, MARATHON alternator

3) Cooling method: closed water cooling

4) Starting method: electric starting
5Rated voltage: 400 / 230V,380/220, etc.

6)Rated frequency: 50 / 60Hz



Alternator feature:

1) Power factor: 0.8 lagging

2) Phase: 3-phase, 4-wire

3) Connection: Y type connection

4) Excitation: brushless excitation

5) Voltage regulation: AVR automatic



Packing: Plywood case or wooden case



Parameter:

Gensets Technical Data of Diesel Engine(50hz/1500rpm) Alternator
Model Gensets power(KW/KVA) Engine
model		 Engine power(kw) Fuel
consumption		 Cylinder
*Bore*Stroke
(Qty*mm*mm)		 Asp. WANTONG
Prime Prime Standby g/kw.h L/h
WT-D33 24 30 D226B-3D 32 35 215 8.1 3×105×120 N/A WT-184G
WT-D40 28 35 D226B-3D 32 35 215 8.1 3×105×120 N/A WT-184H
WT-D50 36 45 TD226B-3 47 51 208 11.5 3×105×120 TC WT-224D
WT-D55 40 50 TD226B-3D 47 51 208 11.5 3×105×120 TC WT-224D
WT-D70 50 63 TD226B-4D 60 66 208 14.68 4×105×120 TC WT-224E
WT-D110 80 100 WP4D120E10 88 97 205 21.22 4×105×120 TC WT-274C
WT-D116 84 105 TD226B-6 93 102 205 22.43 6×105×120 N/A WT-274DS
WT-D140 100 125 TBD226B-6D 124 136 198 28.88 6×105×120 N/A WT-274D
WT-D165 120 150 WP6D185E10 136 150 205 32.8 6×105×120 TC WT-274FS
120 150 TBD226B-6D5 132 145 205 31.84 6×105×120 TC WT-274FS
WT-D220 160 200 TBD234V6 191 210 198 44.49 6×128×140 TC WT-274H
WT-D248 180 225 TBD234V6 191 210 198 44.49 6×128×140 TC WT-274J
WT-D275 200 250 TBD234V6-G 223 245 198 51.95 6×128×140 TC WT-274K
WT-D345 250 313 TBD234V8 281 309 196 64.8 8×128×140 TC WT-C4ES
WT-D385 280 350 TBD234V8-G 310 341 196 71.48 8×128×140 TC WT-C4ES
WT-D415 300 375 TBD236V8 350 385 196 80.71 8×128×140 TC WT-C4FS
WT-D550 400 500 TBD234V12 444 488 196 102.38 12×128×140 TC WT-C5D
WT-D620 450 563 TBD604BL6 500 550 197 115.88 6×170×195 TC WT-C5E
WT-D688 500 625 TBD604BL6 564 620 197 130.72 6×170×195 TC WT-C5FS
WT-D825 600 750 TBD620L6 660 730 193 149.86 6×170×195 TC WT-LV6B
WT-D1100 800 1000 TBD620V8 880 960 193 199.81 8×170×195 TC WT-LV6E
WT-D1400 1000 1250 TBD620V12 1128 1200 187 248.16 12×170×195 TC WT-LV6G
WT-D1650 1200 1500 TBD620V12 1320 1440 187 290.4 12×170×195 TC WT-P17D
WT-D2200 1600 2000 TBD620V16 1760 1920 194 401.69 16×170×195 TC WT-P17G



DEUTZ Diesel Generator

DEUTZ Diesel GeneratorDEUTZ Diesel GeneratorDEUTZ Diesel GeneratorDEUTZ Diesel Generator
