Specifications
Soundproof 30KW/37.5KVA diesel generatorwith YANGDONG engine
with EPA certification.
low noise 30kw silent type diesel power generator set
1) Rated output: 30kw
2) Rated voltage: 400 / 230V, 380 / 220, 220 / 120 etc
3) Rated frequency: 50 / 60Hz
4) Power factor: 0.8
5)Cooling method: closed water cooling or air force cooled
6)Starting method: electric start
7)Rated speed: 1,500 / 1,800rpm
8) Noise level: 75dB to 80dB 7 meter away
9) Alternator Brand: Stamford or Leroysomer or Our WT series
10) Phase: 3-phase, 4-wire
11) Connection: Y or other type connection
12) Excitation: harmonic excitation or phase compound or brushless
13) Voltage regulation: AVR automatic
14) 1.0% voltage regulation (max.) in static conditions
15) Protection class: IP 22 or IP23
Control panel:
1) The generator control panel is manufactured locally by
2) The panel is provided with:
a) Standard engine instrumentation
b) Voltmeter with selector switch
c) Ammeter with selector switch
d) Frequency meter
e) Current transformers
f) Instrument fuses duly wired and ferruled
g) Mcb of suitable rating with overload and short circuit protection
h) With AMF control panel or with ATS (automatic transfer syste)
i) With EPA certification
