100kva Cummins Engine Assemble Diesel Generators Price
Negotiable
MOQ: 5 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Cumins
Model Number:
WT2-C110
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Fujian, China
Brand Name
Cumins
Model Number
WT2-C110
Output Type
AC Three Phase
Speed
1800rpm
Frequency
60HZ
Rated Power
100KVA
Rated Voltage
380/220V
100kva Cummins Engine Assemble Diesel Generators
We are OEM of CUMMINS in China, with long term cooperation. WANTONG-CUMMINS generator set, adopts B,C series engine from Dongfeng Cummins Engine Co., Ltd and N, K, M, Q series engine from Chongqing Cummins Engine Co., Ltd. The complete generator set also includes alternator, base frame, connecting flange, fuel tank, and control system, etc.
Technical data
| Gensets | Gensets Model | WT2-C110 | ||
| Prime power(KW/KVA)(three phase) | 80KW/100KVA | |||
| Automatic control panel | with ATS | |||
| Engine | Engine Model | 6BT5.9-G2 Cummins | ||
| Prime power(KW) | 100KW | |||
| Air Intake System | Turbocharged, water cooling | |||
| Cylinder*Bore*Stroke (Qty*mm*mm) | 6*102*120 | |||
| Compression Ratio | 16.5:1 | |||
| Alternator | Rating Voltage(V) | 3 phase, 380/220V | ||
| Model | WANTONG | WT-224G | ||
| Rating Power(KW/KVA) | 80KW/100KVA | |||
| Rating Frequency/speed | 60HZ/1800rpm | |||
| Rating Power Factor | 0.8 lagging | |||
| Steady voltage regulation | less than ±1.0% | |||
| Phase/Connection | 3 phase, 4 wire/Y type connection | |||
| Excited type/Voltage regulation | Brushless, self excited AVR automatic control |
|||
| Protection | IP22 | |||
| Insulation | Class H | |||
