Specifications
led screen1. High definition LED screen
2. Full color display for background
3. High brightness,high contrast
1. High brightness and widely viewing angle
2. Light weight for easy transportation
3. Vivid style to adapt different structures
4. Easy to installation and disassembly
Available type and pitch size
Indoor: 40mm
Outdoor: 37.5mm
Strip: 40mm
Broadcasting standard
Meet industry top quality requirements, high refresh rate, super image quality and color uniformity, high contrast ratio.
Full-Depth Calibration
Optimize picture uniformity with dot-to-dot calibration. Enable mix usage of products made of different batch.
Super light cabinets
a lighter aluminum cabinet makes it ideal for setup and teardown as well as transportation.
Easy rigging system
Each cabinet contain a strong rigging system to enable easy rigging and adjustments. Unique latching device can keep all display panels on same horizontal line, it also keep the panel as a whole without any aperture.
Product Specification
| Pixel Pitch: | 18.75 mm | 40 mm |
| Brightness: | 5000 cd/sqm | 2000 cd/sqm |
| LED Configuration: | SMD 3 in 1 | 1R1G1B |
| Pixel Density: | 2844 pixels/sqm | 625 pixels/sqm |
| Viewing Angle(Vertical): | 140° | 120° |
| Viewing Angle(Horizontal): | 140° | 60° |
| Cabinet Resolution: | 32*32 pixels | 16*32 pixels |
| LED Lifetime: | 100,000 hours | 100,000 hours |
| Power Consumption(Maximum): | 700 W/sqm | 150 W/sqm |
| Weight: | 8 kg/unit | 8.5 kg/unit |
| Processing: | 12 bit | 12 bit |
| Refresh Rate: | 1500Hz | 600Hz |
| Rotation Angle: | -15° to +15° | -20° to +20° |
| Material: | Aluminum alloy | Aluminum alloy |
| Temperature Range(Operating): | -20 to 60 Degrees Celsius | -10 to 40 Degrees Celsius |
| Humidity Range(Operating): | 10% to 99% | 10% to 99% |
| Protection Rating: | IP 65 | IP 65 |
| Dimension(W*H*D): | 600*600*91 mm | 640*1280*91 mm |
| LED Processor | LINSN | LINSN |
| Signal: | DVI up to UXGA, SDI, HD-SDI, S-video, compositem, YUV | |
System Diagram
