Vivid Big LED Stage Display

Name: Vivid Big LED Stage Display
Brand: LAMP
SKU: 107757483

US$ 1 - 8,000 MOQ: 1 Set

Key Specifications

Place of Origin:

China

Brand Name:

LAMP

Usage:

Indoor

Shenzhen Lamp Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen/Hong Kong

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name LAMP

Usage Indoor

Tube Chip Color Full Color

Display Function Video

Specifications

1.LED display screen
2.Cambered cabinets design screen
3.Vivid indoor video display panel.
4.90+countries experience

Main Features

1.solid aluminum structure to meet the requirements of thousands time of assemble and disasemble.

2.easy hanging structure support fast installation.

3.14-bit color processing enable a vivid color quality.

4.1000HZ refresh rate meet all your needs for broadcasting.

5.top industrial power and data connector from Neutrik enhance the stability for whole system.

6.total solution includes video processor, rental power distribution unit, truss...etc.

Specification

Pixel pitch(mm)	P4	P5	P6	P7.62
Pixels Configuration	1R,1PG,1PB	1R,1PG,1PB	1R,1PG,1PB	1R,1PG,1PB
Module Dimension (L × H) mm*mm	128 × 128	160 × 160	192 × 96	244 × 122
Module Resolution (L × H) pixels*pixels	32 × 32	32 × 32	32 × 16	32 × 16
Cabinet Dimension (L × H) mm*mm	128 × 128	640 × 640	768 × 576	976 ×732
Cabinet Dimension (L × H) mm*mm	128 × 128	640 × 640	768 × 576	488 × 488
Cabinet Resolution (L × H) pixels*pixels	128 × 128	128 × 128	128 × 96	128 × 96
Cabinet Resolution (L × H) pixels*pixels	128 × 128	128 × 128	128 × 96	64 × 64
Density (pixels / M2)	62500	40,000	27,777	17,221
Brightness Density (cd/m2)	4000	2600	2400	1800
Drive mode	1/8	1/8	1/8	1/4
Best Viewing distance (m)	4 ~ 20	3 ~ 100	3 ~ 100	5 ~ 100
Power consumption (Average) (w/ m2)	800	648	450	420
Power consumption (Max) (w/ m2)	1600	1600	1130	1050
Viewing angle	Horizontal angle: 120 degree ; Vertical angle: 120 degree
Gray scale	4096 gray scale in each Red,Green,Blue color
Kinds of Color	68.7 billion kinds
Ingress Protection	Front IP40 , Rear IP30
Refresh Velocity	60 frame/sec
Refresh Rate	300HZ
Display Life	100,000 hours
Display MTBF	10000 hours
Blind Pixels Rate	0.0003
Working Voltage	AC220V±15% , 47~64HZ
Effective Control Distance	100m (kind 5 cable) / 1000m or more (Optical fiber)
Operation temperature	- 30°C ~ + 60°C
Operation Humidity	10% ~ 90% RH
