Help CenterManufacturer Full Color LED Display for Show Stage
Related Products
-
Ligth Weight LED Display Cabinet for RentalUS$ 1 - 8,000MOQ: 1 Square Meter -
Indoor Slim LED Rental DisplayUS$ 1 - 8,000MOQ: 1 Square Meter
-
Modular Design Rental DisplayUS$ 1 - 8,000MOQ: 1 Square Meter
-
Indoor Rental LED Display With Low PowerUS$ 1 - 8,000MOQ: 1 Square Meter
-
Super Light Cabinets Led DisplayUS$ 1 - 8,000MOQ: 1 Square Meter
Specifications
1.slim display2.light-weight,modular design
3.accurate color uniformity and smoother, ficker-free video
4.ulimate display
Manufacturer full color LED display for show stage
-Main Features
Broadcasting standard
Meet industry top quality requirements, high refresh rate, super image quality and color uniformity, high contrast ratio.
Full-Depth Calibration
Optimize picture uniformity with dot-to-dot calibration. Enable mix usage of products made of different batch.
Super light cabinets
a lighter aluminum cabinet makes it ideal for setup and teardown as well as transportation.
Easy rigging system
Each cabinet contain a strong rigging system to enable easy rigging and adjustments. Unique latching device can keep all display panels on same horizontal line, it also keep the panel as a whole without any aperture.
-Specification
Pixel pitch(mm) |
P8 |
P10 |
P12 |
Pixels Configuration |
1R,1PG,1PB |
1R,1PG,1PB |
1R,1PG,1PB |
Module Dimension |
256 × 128 |
160 × 160 |
192 × 192 |
Module Resolution |
32 × 16 |
16 × 16 |
16 × 16 |
Cabinet Dimension |
1024 × 768 |
640 × 480 |
768 × 576 |
Cabinet Resolution |
128 × 96 |
64 × 48 |
64 × 48 |
64 × 64 | |||
Density (pixels / M2) |
15,625 |
10,000 |
6,944 |
Brightness Density (cd/m2) |
1400 |
1200 |
1000 |
Drive mode |
1/4 |
1/4 |
1/4 |
Best Viewing distance (m) |
5 ~ 100 |
5 ~ 100 |
5 ~ 100 |
Power consumption (Average) |
460 |
320 |
240 |
Power consumption |
1145 |
800 |
600 |
Viewing angle |
Horizontal angle: 120 degree ; Vertical angle: 120 degree |
||
Gray scale |
4096 gray scale in each Red,Green,Blue color |
||
Kinds of Color |
68.7 billion kinds |
||
Ingress Protection |
Front IP40 , Rear IP30 |
||
Refresh Velocity |
60 frame/sec |
||
Refresh Rate |
300HZ |
||
Display Life |
100,000 hours |
||
Display MTBF |
10000 hours |
||
Blind Pixels Rate |
0.0003 |
||
Working Voltage |
AC220V±15% , 47~64HZ |
||
Effective Control Distance |
100m (kind 5 cable) / 1000m or more (Optical fiber) |
||
Operation temperature |
- 30°C ~ + 60°C |
||
Operation Humidity |
10% ~ 90% RH |
||
-Application
1. Stage venues
2. Entertainment venues
3. Sports arenas
4. Commercial advertising
