Material Handling Equipment and Warehouse Equipmnt Full Electric Stacker

Material Handling Equipment and Warehouse Equipmnt Full Electric Stacker thumbnail-1
Material Handling Equipment and Warehouse Equipmnt Full Electric Stacker photo-1
US$ 2,000 - 7,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
Baoli
Contact Supplier Request Quote Chat Now
KION Baoli (Jiangsu) Forklift Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name Baoli
Model Number ES15/ES15-P
Type Powered Pallet Truck
Power Souce AC Motor
Rated Loading Capacity 1500kg
Max. Lifting Height 3300-4800mm
Min. Lifting Height 86mm
Fork Length 1140mm
Fork Width 190mm
Overall Dimensions 1925-2010mm
Certification CE, ISO9001, ISO14001
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Capacity:1500kg
Drive unit:electric
Operator type:pedestrian/rider
fork length:1.15m;max height:2~4.8m
CE, ISO9001/14001

Material handling equipment and warehouse equipmnt Full Electric Stacker



Baoli advantages and detailed specifications:



Capacity:1500kg
Drive unit:electric
Operator type:pedestrian/rider
fork length:1.15m;max height:2~4.8m

Electric Pallet Stacker 1.5T   ES15 ES15-P
Load capacity kg 1500 1500
Load center distance mm 600 600
Drive unit   electric electric
Operator type   pedestrian/rider
lift height mm 3300 3300
lowered forks height mm 86 86
fork dimension mm 1140/190/66 1140/190/66
fork overall width mm 570 570
overall length (without platform) mm 1925 2010/2420
overall width mm 850 850
overall height mm 2137
min. turning radius mm 1615
aisle width with pallet 800*1200 mm 2300
aisle width with pallet 1000*1200 mm 2340
travel speed(with/without load) km/h 4.5/5
lift speed mm/s 110/170
lowering speed mm/s 140
max gradeability % 5/10
truck weight(without battery) kg 780 805
tyre size, rear mm ¢230*82
type size, front mm ¢85*90
wheel base mm 1310
min. ground clearance mm 30
service brake   electricmagnetic
battery voltage v/ah 24/270
battery weight kg 260
diver motor   AC24V 1.3KW
lift motor   DC24V 3KW
sound level dB 70





material handling equipment and warehouse equipmnt Full Electric Stacker



About KION BAOLI:

KION Baoli develops, manufactures, distributes and services forklift trucks. As a brand of KION Group, Baoli focuses on the global economy market segment. Since 210 Baoli has been fully integrated and managed by KION Group. The Baoli factory located in Jingjiang(near Shanghai) manufactures a modern and complete electric, IC and warehousing truck range.

material handling equipment and warehouse equipmnt Full Electric Stacker



Factory Gallery:

material handling equipment and warehouse equipmnt Full Electric Stacker



Quality communications between Baoli and customers

material handling equipment and warehouse equipmnt Full Electric Stacker





Baoli at the exhibitions:

material handling equipment and warehouse equipmnt Full Electric Stacker



Industry certificates

 material handling equipment and warehouse equipmnt Full Electric Stacker
