Home > Electrical & Electronics > Passive Components > Resistor & Potentiometer > SC6080GH 60 Travel Slide Potentiometer

SC6080GH 60 Travel Slide Potentiometer

Name: SC6080GH 60 Travel Slide Potentiometer
Brand: APAI
SKU: 107741357
Availability: InStock

SC6080GH 60 Travel Slide Potentiometer thumbnail-1

SC6080GH 60 Travel Slide Potentiometer photo-1

Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

APAI

Model Number:

SC6080GH

Contact Supplier Request Quote Chat Now

Foshan Apai Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name APAI

Model Number SC6080GH

Type Rotary Potentiometer

Technology Carbon Film

Resistance 1-1M

Resistance Tolerance 20%

Rated Power 0.05W

Max. Operating Voltage 50V AC 20V DC

Operating Temperature -10~70

Specifications

APAI potentiometer:
Travel=60mm
L=75mm W=9mm
Solderable with auto dipping and available in a wide variety.

APAI potentiometer:

Travel=60mm

L=75mm W=9mm

Solderable with auto dipping and available in a wide variety.

Various Option for you to chose!

1.Shape of Shaft: B/C/D shaft style

2.Length of Shaft:10/15/20mm

3.Taper and Resistance:

A Taper:1K/2K/5K/10K/20K/50K/100K/250K/500K/1M

B Taper:1K/2K/5K/10K/20K/50K/100K/250K/500K/1M

C Taper:1K/2K/5K/10K/20K/50K/100K/250K/500K/1M

Ect.

(Some taper&resistance maybe out of stock, pls comfirm with us before placing order)

4. Kind of Grease: light/comond/heavy handling feeling

5.Tap: with/wirhout tap

6.Wide variety of travels: 45mm,60mm,100mm

7.Unit:Single-unit/Dual-unit

8.Click:with/without center click(center detent)

9.Dust Proof Cover:with/without

Items	RK12		RK121
	Single-unit	Single-unit	Dual-unit
Total rotational angle	300o±5o
Rotation torque	20 ~200gf.cm
Rotation stopper strength	3kgf.cm
Push-pull strength	5kgf
Shaft wobble	0.7×L/20mm p-p max.

(Electrical characteristics)

Total resistance	1 ~ 1 MΩ	5 ~ 500 KΩ	500~ 1 KΩvgsd
Total resistance tolerance	±20%
Resistance taper	A,B,C,D,W
Rating power (W)	0.05W	0.03W	0.08W
Maximum operating voltage	50V AC 20V DC	50V AC For AC only	100V AC
Slider noise	47mV max.	68mV max.	47mV max.
Gang error		3dB max. (-40~0dB)
Insulation resistance	100 minute at 250V AC
Voltage proof	1 minute at 250V AC
Sliding life	10,000 cycles
