RK164GT 16mm Size Potentiometer

RK164GT 16mm Size Potentiometer thumbnail-1
RK164GT 16mm Size Potentiometer photo-1
Negotiable MOQ: 5000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
APAI
Model Number:
RK164GT
Contact Supplier Request Quote Chat Now
Foshan Apai Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name APAI
Model Number RK164GT
Type Rotary Potentiometer
Technology Carbon Film
Resistance 500-500K
Resistance Tolerance 20%
Rated Power 0.05W
Max. Operating Voltage 0.08W
Operating Temperature 38-42

Specifications

APAI potentiometer supply wide range of versatility products applicable for various types of control.Dual-unit and rotary swit

APAI potentiometer:

Items

RK123

RK124

RK126

Single-unit

Single-unit

Dual-unit

Dual-unit

Single-unit

Total rotational angle

300o±5o

Rotation torque

20 ~200gf.cm

Rotation stopper strength

5kgf.cm min.

Push-pull strength

8kgf

Shaft wobble

04×L/25mm max.

(Electrical characteristics)

Total resistance

5KΩ ~ 500 KΩ

Total resistance tolerance

±20%

Resistance taper

A,B,C,D,W

Rating power (W)

0.05W

Maximum operating voltage

B Taper 0.08W Other taper 0.04W

Slider noise

47mV max.

Gang error

3dB max.
(-40~0dB)

3dB max.
(-40~0dB)

Insulation resistance

100MΩ min. at 500V DC

Voltage proof

1 minute at 100V AC

Sliding life
