WPC Mould for Wood Plastic Composite Wall Panel WPC Cladding

Specifications

Wall Panel WPC Cladding mould
1.Stable performance
2.Material:3Cr17,3Cr17NiMoV,DIN2316
3.Various size ahd shape

 Wall Panel WPC Cladding Mould

Name	WPC Mould for Wood Plastic Composite Wall Panel WPC Cladding
Mould material	3Cr17, 3Cr17MoNiV, DIN1.2316 or as per your request
Mould cavity	One or multi-cavity
Mould composition	Die head, aluminum heating panels, calibrators and water tank
Feature	High polished surface, stable discharging, soft-hard, surface layer, cladding
Test	Mould will be tested to get the satisfy sample before delivery
Sample	Sample will be arranged by express for customer approval
Service	Provide complete set of formulation, technology and perfect after sale service



 Our extrusion mould advantages:



1.we are founded in 2001,.extend 13 years professional experennce gives us dominate position in extrusion moluld industry., quality and precision are the most import target of our company.our products enjoy an excellent reputation in plastic extrusion mould industry.





2.We owned a team of mature and experienced technicians,rich experiences  workers from design, manufacture and debugging department.



3.We can make all kinds of moulds according to customer requirement.The mould can be extrusion profile, color co-extrusion, embossing co-extrusion, surface layer and so on.



4.Provide complete set of production process and technology transfer service .



5. Flow channel systematic design is based on theoretical calculation, practical conclusion, adopting reasonable compressing ratio and stain technology according to different formula and technique





 DIE



1) Die design is based on flow simulations on our computer, flow analysis and experience, that leads to excellent flow characteristics.



2) High precision positioning pin design guarantees accurate plate assembly



Calibrator



uses high efficient vacuum device and cooling system design to guarantee great quality of finished products and smooth profile surface



Water/vacuum tank



a) Newly designed water/vacuum tanks supply vacuum and cooling water



b) High quality materials and unique design ensures high efficient cooling and proper seal to maintain constant water and vacuum supply in the tank



c) Self adjusting templates guarantee final sizing of profile



d) Tank material available: Plexiglas or fiberglass



e) High-sealing vacuum water tank of PVC window mould adopts floating setting design, able to adjust automatically





Moulds we made:

















Fine quality after-sale service:



1.Our company has high level of technology,rich experiences in testing mould and good reputation service team.



2.Principles of service:  First testing combined with tracking service



                                         Orientation services linked with peripatetic service



                                         Technical services united with training endorsement



3.Replying clients' problems in time ,and the technical can be arrived in three days.



4.One year warranty for the mould,and maintain for the whole life.



Product test results



NO.	Test Items	Technical Requirements	Units	Measured Value	Single Conclusion
1	Extrusion speed	0.8-1.8	m/min	0.87	conform
2	Yield	>98	%	99	conform
3	Thickness deviation	<1.2	mm	0.24	conform
4	Water absorption	≤3.0	%	1.0	conform
5	Density	≥0.85	g/ cm³	1.38	conform
6	Tightness	No leakage	/	conform



Product line:



Mould composition:



Our export mould :



Package:



Sample application:









Certificate:

Our company:







Website: www.jinghuamould.en.china.cn



Add: Machinery Industrial Park, Huangjinshan New Area ,Huangshi,Hubei,China mainland



Hubei Province Wuhan tianhe airport:90 Minutes by car to our company





 If you are interested in our moulds, please feel free to contact with us and show us your sample picture or drawings.We will do our best to provide you with competitive price and professional service!
