Gear Driven Horizontal Drilling Machine Horizontal Vertical Drilling Milling Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Place of Origin:
Anhui, China
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
3 in 1 Multi-purpose Lathe Machine Multi-purpose Mill Drill Head Lathe MachineNegotiableMOQ: 1 Set -
Multi-purpose Lathe Drilling Milling Machine Multi-purpose Combo Drilling Milling Lathe MachineNegotiableMOQ: 1 Set
-
3 in 1 Multi-purpose Lathe Machine Multi-purpose Mill Drill Lathe MachineNegotiableMOQ: 1 Set
-
Ball Screw Drilling Machine Horizontal Vertical Drilling Milling MachineNegotiableMOQ: 1 Set
-
3 in 1 Multi-purpose Lathe Machine Multi-purpose Mill Drill Head Lathe MachineNegotiableMOQ: 1 Set
Condition
New
CNC or Not
Normal
Place of Origin
Anhui, China
Model Number
ZX7550CW
Voltage
Customer's Requirement
Power(W)
V:0.85KW/1.5KW , H:2.2 KW
Weight
850 kg
Certification
CE Standard
After-sales Service Provided
Engineers available to service machinery overseas
Gear Driven Horizontal Drilling Machine Horizontal Vertical Drilling Milling Machine
Specification |
ZX7550 |
ZX7550CW |
|
Max. Drilling dia. |
50 mm (2'') |
||
Max.horizontal milling dia. |
100 mm |
||
Max.vertical milling dia. |
25 mm |
||
Max.boring dia. |
120 mm |
||
Max.tapping dia. |
M 16 |
||
Spindle taper |
MT 4 ,ISO30,R8 |
||
Spindle speed range (V/H)(r.m.p) |
(8step)115-1750 /60-1350 |
(8step)230-1825/60-1350 |
|
Spindle travel |
120 mm |
||
Table size |
800x240 mm |
||
Table travel |
400x230x380 mm |
||
Main motor power (V/H) |
V:0.85KW/1.5KW , H:2.2 KW |
||
N.W/ G.W |
850KG/1000KG |
||
