Specifications
1.Eps Sandwich Wall Panel2.Material:eps,csb,cement,fly ash
3.Anti-earthquake
4.Eco-friendly
5.CE, ISO.
Eps Sandwich Wall Panel
Specifications:
Composition:
Calcium silicate board(face panel) + Cement and EPS(core) + Calcium silicate board(face panel)
Size(L*W*T):
1500-3000mm * 610mm* (60, 90,120,150,180mm)
.Advantages:
Energy-saving, environment-friendly, fire proof, water proof, increased the usable area, anti-pressure, anti-quake, anti-impact, sound insulation,heat insulation and preservation, simple construction, high efficiency, spiking, stickability, light weight and economy and so on.
Performance Index:
NO. |
Item |
National Standards |
Testing Results |
||||
60mm |
90mm |
120mm |
60mm |
90mm |
120mm |
||
1 |
Anti-impact performance/times |
≥5 |
≥5 |
≥5 |
≥6 |
≥6 |
≥10 |
2 |
Anti-bending damage load/times over deadweight |
≥1.5 |
≥1.5 |
≥1.5 |
≥3 |
≥3 |
≥3 |
3 |
Anti-pressure strength /Mpa
|
≥3.5 |
≥3.5 |
≥3.5 |
≥6 |
≥6 |
≥6 |
4 |
Surface density kg/m2 |
≤70 |
≤90 |
≤110 |
≤45 |
≤54 |
≤66 |
5 |
Single point hanging Strength /N |
≥1000 |
≥1000 |
≥1000 |
≥1000 |
≥1200 |
≥1300 |
6 |
Fire proof limit /h |
≥1 |
≥1 |
≥1 |
≥3 |
≥3 |
≥4 |
7 |
Sound insulation capacity in the air /Db |
≥30 |
≥35 |
≥40 |
≥35 |
≥40 |
≥45 |
8 |
Soften coefficient |
≥0.80 |
≥0.80 |
≥0.80 |
≥1 |
≥1 |
≥1 |
9 |
Moisture rate a/% |
≤12 |
≤10 |
≤10 |
≤10 |
≤9 |
≤7 |
10 |
Heat transfer coefficient b/w/m2.k |
≤2.0 |
≤2.0 |
≤2.0 |
≤1.0 |
≤0.6 |
≤0.5 |
11 |
Drying shrinkage /mm/m |
≤0.6 |
≤0.6 |
≤0.6 |
≤0.45 |
≤.0.5 |
≤0.5 |
12 |
Inner radiation index
|
≤1 |
≤1 |
≤1 |
≤1 |
≤1 |
≤1 |
13 |
Outer radiation index
|
≤1 |
≤1 |
≤1 |
≤1 |
≤1 |
≤1 |
14 |
Radioactivity Limit |
≤1 |
≤1 |
≤1 |
≤1 |
≤1 |
≤1 |
Supplied to: Iran, Australia, Chile, Portugal, Oman, Bahrain, Emirate and so on.
Welcome to your enquiry and test the sample, visit our factory, we shall with highly pleausre to service for you.:-)
