Optical fiber cable accessory splice closure
- 10000 Piece / Pieces per Month
- chongqing /shanghai/ shenzhen
- T/T Credit Card
- ZTE 5928E, RS-5928E, RS-59EC-PWR-AC10, RS-59EC-PWR-DC10, 24 GE RJ45 + 1 expansion card ZTE ZXR10 5928E 5952E 5916E RS-5916E RS-
- ZTE 2952E, RS-2952E-AC, RS-2952E-DC, 48 FE RJ45 4 GE SFP ZTE ZXR10 2952E 2928E 2918E 2910E
- ZTE 3950-28TM, RS-3950-28TM-AC, 24 FE RJ45 + 2 GE SFP + 1 expansion card slot ZTE ZXR10 3950
- ZTE 2950-18TC, RS-2950-18TC-AC, 16 FE RJ45 + 2 GE Combo ZTE ZXR10 2950
- ZTE S2XF48A, 48-port 10GE SFP+ optical interface ZTE ZXR10 8902E 8905E 8908E 8912E RS-8902E RS-8905E RS-8908E RS-8912E
- ZTE 5250-28PM-H, RS-5250-28PM-H, 20 GE RJ45 (POE/POE+) + 4 GE Combo ports + 1 expansion card ZTE ZXR10 5250
Product Details
Place of Origin: | Sichuan, China | Brand Name: | Yuantong | Model Number: | fiber closure |
Product Description
Optical fiber cable accessory splice closure
Product Description
Fiber Optic Closure is designed to be comprised of PLC splitters allowing optical power to be split. The easy-to-sure gasket sealing system further simplifies the installation process and provides superior protection from external environments. It can be used in FTTH applications and shall be served with all of the mechanical requirement such as waterproof, impact resistance and securing feeder and drop cables, included two optical splice trays shall be used for PLC splitter installations and drop cable splicing.
Installation Methods
Aerial, Duct, Manhole
Specification
Item | Value |
Dimension(mm) | 293Lx183Wx98H |
Weight | 1.6kg |
Cable input capacity & cable size (mm) | Max 6 ports (2 ports for Φ3.5, 4 ports for Φ8) |
Cable output capacity & cable size (mm) | Max 8 ports (Φ3.5) |
Max splice capacity | 48 core |
Operation temperature | -40 ~ +85℃ |
Features
1. Can accommodate up to 1x16 PLC splitter on the splice tray
2. Special drop grommet for cable
3. Compact size, light weight
4. High impact resistant and UV resistant thermoplastic for long life
5. Hinged tray structure
6. Bending radius: 15mm for RN Tray (1x4, 1x8, 1x16 splitter available)
8. Easy to assemble
Certification
Paking and shipping
Our Services
Firstly, we are manufacturer for the truth, we can control the quality, delivery time, cost of rawmaterial, in this way, we can provide you with high-end products, competitive price and surpb service.
Secondly, we have a very professional sales team, who are very familiar with all kinds of overseas trading terms and custom clearance documents in this way we will make your import process very smoothly and pleasantly.
Thirdly, your inquiry will be took seriously and replied immediately within 24 hours, ifthe inquiry is complicated, we will reply you the second day.
Last but not the least, we have gained Alibaba trade assurance so there’s no worry about out quality.
Sichuan Yuantong communication Co.,Ltd is a company specializing in the development of optical communication products, production, sales and with independent right of high-tech enterprises.
Address: Chengdu Southwest Airport Economic Development Zone, from the Shuangliu Airport, highway takes only a few minutes.
Scale of company: More than 4000 square meters (office building area 1200 square meters, plant construction area of 2500 square meters, containing optical fiber cable workshop, workshop, extrusion workshop, preparatio workshop)
Main product: the covered optical cable,indoor cable and FTTH professional solution for the whole series of products
Our market: United states, Brazil, Europe, the middle East and Southeast Asia and many other countries
