Help Center2-10kg/bag Pellet Packing Machine
Related Products
-
Hot Sell Packing Machine for Wood Pellets,feed PelletsUS$ 3,000 - 4,000MOQ: 1 Set -
Wood/sawdust Pellet Packing MachineUS$ 3,000 - 4,000MOQ: 1 Set
-
Automatic Wood/sawdust Pellet Packing Machine With 5-5okg/bagUS$ 2,000 - 4,000MOQ: 1 Set
-
2013 Automatic Sawdust Pellet Packing Machine for SaleUS$ 2,000 - 4,000MOQ: 1 Set
-
2013 Hot Sale! Fully Automatic Sawdust Pellet Packing MachineUS$ 2,000 - 4,000MOQ: 1 Set
Specifications
1.Auto filling system2.Auto weighting balance
3.Auto belt conveyor
4.Auto sewing machine or Auto heat sealing machine
Description
The system is applied to quantitative automatic weighing, filling, kneading, accumulating weigh and times, stitching and conveying with manual assistant for powder, pellet material in the factory or other industry.
Features
1) Take three speeds feeding to guarantee the precision at min weight and the speed at max weight.
2) The head of bag stitching machine, conveyor, and hot sealing machine can rise and fall. And at the same time, the system is applied to sealing and convey with max and min bags.
3) There is shock-absorbing device in weighing system; it could avoid the shock of other devices through floor and tube to affect the weighing system.
4) There is good seal in system, and it has dust catcher and aspirator.
5) The is guide groves in conveyor roller and guide bars in conveyor belts to avoid cracks.
Function
1 .There is detecting device in system.
2 .Processes function of automatic modifying drop height.
3. Processes function of self-test, error pilot and fault code indication.
4.With the serial interfere to communicate the computer.
5.With five-figure password to control the accumulator in system.
6.Pre-set filling number in system.
Main Data and Price
Model |
Description |
Dimensions (mm) |
Weight (kg) |
Speed |
ZCS-10 |
2-10kg/pc |
1500*800*2000 |
300 |
180-240pc/h at slow speed 260-330pc/h at middle speed 500-600pc/h at fast speed |
ZCS-25 |
15-25kg/pc |
2200*880*2300 |
500 |
|
ZCS-50 |
25-50kg/pc |
2300*900*2300 |
600 |
