Crusher Machine/soybean or Peanut Crusher/roller Crusher

Introduction about crusher machine:

Soybean crusher is main machine in pretreatment production line. The soybean is crushed well or bad, which can affect directly the capacity of flaker and effect of flake piece. Meanwhile it can also affect the bleaching indicator because the powder rate is too high. YPSG series crusher produced by our company is a new machine with big capacity and designed successfully first in our nation according to the international advanced crushing theory and actual condition of oil and fatty process factories. Which get good result in practice and reach expectant design theory. It adopts “thread against thread” cutting theory and double-deck teeth rollers working ways. Upper teeth rollers are rough teeth working, down is fine teeth working, it can crush different size oil plant. It has below features: big capacity, crushing fineness can be adjusted, perfect shape structure and driving structure design, it gets high evaluation from oil and fatty expert in production practice for many years, in the meanwhile, it can also compare with abroad machine.

Main data:

YPSG250×1000 Two double rollers crusher

Handling capacity:150-200t/d
Crushing fineness:1/8-1/4pieces
Powder rate out of machine: less than 4%
Matched power:11kw-6*2
Feeding power:0.37KW
Dimension: 1970×1200×1600(mm)
Weight:3T

YPSG250×800 Two double rollers crusher

Handling capacity:100-120t/d
Crushing fineness:1/8-1/4pieces
Powder rate out of machine: less than 4%
Matched power:7.5kw-6*2
Feeding power:0.37KW
Dimension: 1750×1200×2100(mm)
Weight:2.5T

YPSG250*500 Two double rollers crusher

Handling capacity: 60—80t/d

Crushing fineness: 1/4—1/8pieces

Powder rate out of machine: less than 4%

Main power: 7.5kw×2

Feeding power: 0.55kw

Weight: 2.2T

Dimension: 1240×660×1480mm
