hazardous location cool white 45 watt Led explosion-proof lighting RFBL158-L48
Which areas need explosion proof light?
It meets outdoor, construction site.
Ideal for use in oil fields, chemical plants, power plants, petroleum, painting areas
What is the benefit and feature of our explosion proof light?
1. using the highest of Explosion-proof grade , in flammable and explosive area to safe work
2. Led light source, high brightness, longevity.
3. optical design ensure all of range lighting
4. The aluminum body is powder coated for anti corrosion, which is dust and water proof
5. hollow cooling structure control the temperature make sure the light work stable.
6. Various installation options, easy and quickly
what is the parameters of our explosion proof light?
| No | Specification | unit | Reference values | ||
| 1 | Input Voltage | V | 90-265 | ||
| 2 | Frequency | Hz | 50/60 | ||
| 3 | Light source(LED) | Power | w | 24 | |
| 36 | |||||
| 45 | |||||
| Luminous flux | 24 | lm | 2500 | ||
| 36 | 3700 | ||||
| 45 | 4700 | ||||
| service life of light source | h | 100000 | |||
| 4 | The introduction of cable(diameter) | mm | 8~12 | ||
| 5 | Dimensions | out diameter | mm | 200 | |
| Length | 280 | ||||
| 6 | weight | kg | 5.5 | ||
| 7 | Screw thread of inlet | G3/4'' | |||
| 8 | Protection grade | IP65 | |||
| 9 | Anti Corrosion | WF2 | |||
| 10 | Insulation Grade: | I | |||
| 11 | Ex code: | Exde II C T6 | |||
Explosion proof light installation drawing
Explosion proof light light distribution curve
Related Explosion proof light Some of model light have three rated power for your select , satified to your different demands.
| RFLB103 | RFLB153 | RFLB156 | RFBL164 | RFLB165 |
| RFLB104 | RFLB154 | RFBL160 | RFLB162 | |
| RFLB105 | RFLB155 | RFLB157 | RFLB161 | |
Packaging Details: regular packing or customized, The volume of the box is 29cmx28.5cmx30.5cm
Delivery Detail: sample within 3-7 day , batch product within 7-25days
Packing picture
What is our promised of quality Guarantee ?
Thank you for purchasing the products of Wenzhou Recen Lighting Electrical Co., Ltd.. Our products are in strict accordance with the ISO9001 quality control standards. The product warranty is for 3 years (Light bulb for 1 year). In three years, any failure under normal use is repaired by our company for free (Free materials and repairs). contact our company's marketing service department, and we will provide you with high quality and efficient services.
Why us?
Because we believe in providing quality not just the first time, but every time:
•High Customer satisfaction
• Various of products
• Competitive price
• OEM/ODM are welcomed
OUR Factory
Our Fair
explosion proof light patents and ISO 9001:2008
Recen CCC certification , business license and trade mark.
RECEN tax registration certification and Organization-Code-Certificate
Q: Which areas need to use explosion-proof light?
A: It meets the standards and requirements for hazardous environments. Ideal for use in oil fields, chemical plants, power plants, petroleum, painting areas and areas with dust.
Q: What is the advantage of explosion-proof light?
A: It make the worker more safe, because the lamp having function with explosion-proof, dust proof and water proof. In flammable and explosive area to safe work.
Q: Do Led have a longer life than incandescent bulbs?
A: Yes. Incandescent bulb generally last 500-2000 hours, whereas Led may last for 20000-50000 hours or around 20-40 years. this means Led may last 25 times longer than incandescent.
Q: Do the surface of lamp will rust?
A:No, we choose the advantage spay printing of surface, no rust, do not change color, anti rain, could be use outfield for a long terms
Q: How does your factory do regarding quality control?
A: Quality first. We always attach great important to quality control form begin to end. Our factory has gained CCC,CQC authentication.
