Cheapest HD Wifi Mini Camera IP Wifi IP Camera 128G Voice Record P2P Mini Wifi IP Camera

Name: Cheapest HD Wifi Mini Camera IP Wifi IP Camera 128G Voice Record P2P Mini Wifi IP Camera
Brand: Hichip or OEM
SKU: 107560159

US$ 10 - 30 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Hichip or OEM

Model Number:

HX8135SW

Shenzhen Hichip Vision Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Yantian

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Hichip or OEM

Model Number HX8135SW

Type IP Camera

Style Dome Camera

Sensor CMOS

Technology NetWork

Special Features Other, Infrared

Cheapest HD Wifi Mini Camera IP Wifi IP Camera 128G Voice Record P2P Mini Wifi IP Camera

Features:

1/4" 1.0 megapixel progressive CMOS sensor; Hi3518E
H.264 double streams compression
Resolution: 720p(1280*720), 25fps (PAL)/30fps (NTSC)
1CH Audio input (G.711/G.726), 1CH Audio output, Two way audio
Support Alarm Prerecord
support P2P Plug and Play
Support Mobile phone View
Support MAX 128G TF Card record and capture; support motion detection, Email, FTP
Support ONVIF
built-in 802.11b/g/n wireless network module
10m IR Distance

Specification:

Camera	Operating system	embedded Linux
	Processor	GK7102
	Image sensor	1/4” 1.0 megapixel progressive CMOS sensor
	Minimum illumination	0.4Lux
	Lens	3.6mm
	IR Distance	8m night vision
Compression standard	Video compression	H.264 Main profile
	Audio compression	G.711A
	Compression transmission rate	32Kbps-6144Kbps, can self-defined, default is1536Kbps
		first stream: 720P(1280720) and Q720P(640352) optional
		sub stream: Q720P(640352) and QQ720P(320176) optional
	Video frame rate	20fps(50HZ), 20fps(60HZ)
	OSD	support OSD name and Time OSD (on and off available)
	Image setting	Brightness, Contrast, Saturation, Exposure, Flip and Mirror are adjustable
	Video mask	can set four mask area, color of mask area can be set
Function	Storage	Max 128G TF Card, support timing record storage
	Motion detection	can set 4 independent detection area (sensitivity is 1-100 adjustable)
	Alarm linkage	sending pictures to named mailbox; upload pictures to FTP server
	Network protocol	TCP/IP,HTTP,TCP,ICMP,UDP,ARP, IGMP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPNP,RTSP, and so on
	Access protocol	support ONVIF, support purview check(default close purview check)
Port	Audio Input	built-in Microphone
	Audio Output	built-in speaker
	WIFI	WIFI 802.11b/g/n
common specification	Power supply	USB 5V 1A
	Power consumption	4W
	Size	108mm X 68mm (HXW)
	Operating temperature	0 ~ +55 ℃
	Operating humidity	10 ~ 95%RH
