BK7, UV grade Fused Silica Protected Silver Metallic Coated Mirror
Metallic Coated Mirror is an object with a surface that has good specular reflection.Mirror is a smooth,highly polished surface covered a thin coating,It is usually a thin coating of metal or dielectrics.
Parameter
| Material: | BK7 ; UV Fused Silica ;other optical glass |
| Dimension Tolerance: | +0.0, -0.1mm |
| Thickness Tolerance: | ± 0.1mm |
| Surface quality: | 60/40 |
| Clear Aperture: | >85% |
| Flatness: | λ/4 per 25mm@633nm |
| Parallelism: | <3' |
| Bevel: | <0.25mm X 45° |
| Coating: |
One surface(S1) :Polished and Metallic coating (Al, Ag, Au) The other surface :Fine ground |
|
Protected Aluminum :Ravg> 85%@400nm-800nm VIS Enhanced Aluminum :Ravg> 90% @450nm-750nm UV Enhanced Aluminum :Ravg > 80%@250nm-400nm Protected Silver :Ravg > 90% @400nm-20μm Protected Gold :Ravg > 94% @650nm-16μm |
