stainless steel 90 degree double slot square tube

Specifications

90 degree double slot square tube
1.800#-1000# mirror finish,satin,grit,HL
2.size:50.8*1.5*6000mm
3.length custom offered

  stainless steel 90 degree double slot square tube



STANDARD: ASTM A554/268/A269/A249/A270
Grade : 304 304L 316 316L
ASTM A554	slotted handrail tube
	Product	OD(mm)	SLOT(mm)	Thick(mm)		Excellent Finish	Usage
	Single Slot Oval Tube	40X60-40X110	15*15-26*33	1.0-2.5		1)mirror 600#  2)super mirror800#-1000#  3)Titanium Coated-Gold Plated.	handrail & glass
	Single/Double(90/180°)Slotted Round Tube	25.4-88.9	15*15-26*33	1.0-2.5
	Single/Double Slot Square Tube	25X25-50X100	15*15-26*33	1.0-2.5
	Round/Square/Rectangular/Oval Tube
	Round/Circular Tube	6-159		0.5-5.0		Excellent Finish	Usage
	Square Tube	10X10-150X150		0.5-4.0		1)mirror 600#  2)super mirror800#-1000#  3)Titanium Coated-Gold Plated.	decoration project,window,furniture,handrail,railing,glass armrest,upholstery,etc
	Rectangular Tube	20X10-60X120		0.5-4.0
	Special Flat Rectangular Tube	10X30-15X75		1.0-2.0
	Oval/Elliptical Tube	20X40-60X120		1.0-2.5
	Normal Polish: 180#.240#.320#(Satin Finish.).400#(bright finish).Mill finish(2B).Hariline Finish(HL/Brushed).
Stainless Steel Pipe For Industry Instrument Field
ASTM A268	OD(mm)		Thick(mm)				Remark
	15.9-108		1.0-2.0				MOQ:1ton
	Usage: Automobil Exhaust(grade 409 409L 439 436 etc)
ASTM A269	OD(mm)		Thick(mm)				Remark
	6.35-152.4		0.5-3.0				MOQ:1ton
	Usage: medical instrument,chemical industry
	Process: Inline annealed &pickled (with bright surface), steel seal printed
ASTM A249	OD(mm)		Thick(mm)				Remark
	12.7-152.4		0.7-3.0				MOQ:1ton
	Usage: condenser, boiler,heat-exchanger,,etc
ASTM A270	OD(mm)		Thick(mm)				Remark
	19.1-152.4		1.2-2.77				MOQ:1ton
	Usage:Milk and food industrial.



Specification of Single slot ROUND tube:
OD(mm)		SLOT(mm)		Thickness(mm)
25.4		12*12		1.0~1.5
42.4		24*24/20*20		1.2~2.0
48.3		27*30		1.2~2.0
50.8		15*15		1.2~2.0
60.3		34*34		1.2~2.0
63.5		20*20		1.2~2.0
76.2		25*25		1.2~2.0



remarks as below: stainless steel 90 degree double slot square tube

1. sample is available

2. mill test certification & ODM offered

3. buyer's lable accepted

4. quotation are on FOB/ CIF/ CNF basis

5. payment by T/T or L/C: 30% deposit and balance before shipment, as usual practice.

6. surface treatment (polish): 320# satin, grit, 400#~800# mirror, 1000# super mirror, titanium gold plated

7. 304 Ni component is over 8%, 316 is over 10%

8. standard length in 6000mm per piece, nevertheless it's customized for clients.

9. packing methods: bundle (double plastic bags, shrink film, iron cases, cardboard tube)

10. port of loading: Foshan, Huangpu, HK, Shenzhen

11. prompt delivery: 25 days after deposit in usual practice, depend on quantity



glass installing: stainless steel 90 degree double slot square tube

glass would be insert into the slot, rubber is needed, allow us to do some recommendation as below:



slot size(mm)                               glass thickness(mm)

  15*15                                                  5-12mm

  20*20                                                  8-15mm

  25*25                                                  8-22mm

  25*30                                                 10-22mm



packing methods: stainless steel 90 degree double slot square tube

diversified & selected packing methods to protect the tubes from being scratched or getting damaged durng delivery:



1. each tube sleeved in a plastic bag, then put in cardbox with strips

2. each tube sleeved in a plastic bag, then packed in bundles/steel crates.

3. each tube sleeved in a plastic bag, then packed in  cardboard tubes, both sides with end cap, lastly packed in steel crate.

4. 304 in green packing: green plastic bag and green painted steel case.

5. 316 in red packing: red plastic bag and red painted steel case.





why choose Zhangyao?

1.high quality polish,especially mirror finish with adorable price.

2.high Class Taiwan-owned factory with strict quality control management.

3.the most experienced team for slotted tube field in china.

4.introduced the most advanced pipe-making from Taiwan.

5.export percentage: 80%-90%

6.excellent pre-sales,sales,after-sales service.

7.endeavour to develop new products accorrding to your requirement.

what is mirror polish?

600#/800#/1000#------your eyes and tooth could be seen very clearly from tube surface just like mirror

what is bright shinny finish?

400#/500#------- only profile of your face could be seen from round tube.







 contact us







Cream

mob: +86 13690595700 (English, Cantoneses, Mandarin) my phone is 24 hours an call for you:))

skype: cream tan

dep: department of foreign trade

company: Foshan Zhangyao Stainless Steel Appliances CO., LTD.

add: 3#, Area Ganxian Cun Industrial District Chencun Town Shunde Area Foshan City Guangdong Province, China

tel: +86 (0757) 23831039

fax: +86 (0757) 23831036

reception: we'd like to meet you at the airport or hotel. warmly welcome to visit our factory.





offering you high quality products with compectitive price & considerate service without compromising on prompt delivery is our objective, looking forward to cooperate with you, my dear friends !
