customized steel pipe in defferent shape

Specifications

customized steel pipe in defferent shape
1.800#~1000#super mirror
2.100*15*100*2.0mm
3.length custom
mpt delivery



customized steel pipe in defferent shape



STANDARD: ASTM A554/268/A269/A249/A270
Grade : 304 304L 316 316L
ASTM A554	Stainless Steel U Banister Railing/Slotted Tube
	Product	OD(mm)	SLOT(mm)	Thick(mm)		Excellent Finish	Usage
	Single Slot Oval Tube	40X60-40X110	15*15-26*33	1.0-2.5		1)mirror 600#  2)super mirror800#-1000#  3)Titanium Coated-Gold Plated.	handrail & glass
	Single/Double(90/180°)Slotted Round Tube	25.4-88.9	15*15-26*33	1.0-2.5
	Single/Double Slot Square Tube	25X25-50X100	15*15-26*33	1.0-2.5
	Round/Square/Rectangular/Oval Tube
	Round/Circular Tube	6-159		0.5-5.0		Excellent Finish	Usage
	Square Tube	10X10-150X150		0.5-4.0		1)mirror 600#  2)super mirror800#-1000#  3)Titanium Coated-Gold Plated.	decoration project,window,furniture,handrail,railing,glass armrest,upholstery,etc
	Rectangular Tube	20X10-60X120		0.5-4.0
	Special Flat Rectangular Tube	10X30-15X75		1.0-2.0
	Oval/Elliptical Tube	20X40-60X120		1.0-2.5
	Normal Polish: 180#.240#.320#(Satin Finish.).400#(bright finish).Mill finish(2B).Hariline Finish(HL/Brushed).
Stainless Steel Pipe For Industry Instrument Field
ASTM A268	OD(mm)		Thick(mm)				Remark
	15.9-108		1.0-2.0				MOQ:1ton
	Usage: Automobil Exhaust(grade 409 409L 439 436 etc)
ASTM A269	OD(mm)		Thick(mm)				Remark
	6.35-152.4		0.5-3.0				MOQ:1ton
	Usage: medical instrument,chemical industry
	Process: Inline annealed &pickled (with bright surface), steel seal printed
ASTM A249	OD(mm)		Thick(mm)				Remark
	12.7-152.4		0.7-3.0				MOQ:1ton
	Usage: condenser, boiler,heat-exchanger,,etc
ASTM A270	OD(mm)		Thick(mm)				Remark
	19.1-152.4		1.2-2.77				MOQ:1ton
	Usage:Milk and food industrial.



remarks as below: customized steel pipe in defferent shape

1. sample is available

2. mill test certification & ODM offered

3. buyer's lable accepted

4. quotation are on FOB/ CIF/ CNF basis

5. payment by T/T or L/C: 30% deposit and balance before shipment, as usual practice.

6. surface treatment (polish): 320# satin, grit, 400# or 500# is only shiny bright polish,not real mirror polish,  600#~800#mirror, 1000# super mirror, titanium gold plated

7. 304 Ni component is over 8%, 316 is over 10%

8. standard length in 6000mm per piece, nevertheless it's customized for clients.

9. packing methods: bundle (double plastic bags, shrink film, iron cases, cardboard tube)

10. port of loading: Foshan, Huangpu, HK, Shenzhen

11. prompt delivery: 25 days after deposit in usual practice, depend on quantity



glass installing recommendation: customized steel pipe in defferent shape

glass would be insert into the slot, rubber is needed, allow us to do some recommendation as below:



slot size(mm)                               glass thickness(mm)

  15*15                                                  5-12mm

  20*20                                                  8-15mm

  25*25                                                  8-22mm

  25*30                                                 10-22mm

packing methods: customized steel pipe in defferent shape

diversified & selected packing methods to protect the tubes from being scratched or getting damaged during delivery:



1. each tube sleeved in a plastic bag, then put in cardbox with strips

2. each tube sleeved in a plastic bag, then packed in bundles/steel crates.

3. each tube sleeved in a plastic bag, then packed in  cardboard tubes, both sides with end cap, lastly packed in steel crate.

4. 304 in green packing: green plastic bag and green painted steel case.

5. 316 in red packing: red plastic bag and red painted steel case.











why choose Zhangyao?

1.high quality polish,especially mirror finish with adorable price.

2.high Class Taiwan-owned factory with strict quality control management.

3.the most experienced team for slotted tube field in china.

4.introduced the most advanced pipe-making from Taiwan.

5.export percentage: 80%-90%

6.excellent pre-sales,sales,after-sales service.

7.endeavour to develop new products accorrding to your requirement.

what is mirror polish?

600#/800#/1000#------your eyes and tooth could be seen very clearly from tube surface just like mirror

what is bright shinny finish?

400#/500#------- only profile of your face could be seen from round tube.
