Orange Juice Bottling Machine Filling Monobloc

Name: Orange Juice Bottling Machine Filling Monobloc
Brand: Chenyu
SKU: 107521653
Availability: InStock

US$ 4,000 - 40,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Beverage

Packaging Type:

Bottles

Suzhou City Chenyu Packing Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Beverage

Packaging Type Bottles

Packaging Material Plastic

Automatic Grade Automatic

Driven Type Electric

Power up to the capacity

Place of Origin Jiangsu, China

Brand Name Chenyu

Model Number RCGF

Specifications

orange juice bottling machine filling monobloc
1. juice bottling: 2000-30000BPH
2. PLC control fully auto 4 in 1
3. for juice

orange juice bottling machine filling monobloc

juice filling machine, juice pulp machine

It is used for filling pulp juice in PET bottle with plastic screw cap. we can supply the turnkey and installation running service.

Characteristics:

1. it can carry out washing pulp filling, liquid juice filling and capping in one machine.

2. it is very convenient to change diverse sizes of bottles by means of advanced bottle neck clamping & bottle suspending technology.

3. Advanced programmable PLC is equipped to control the main machine. Working speed can be adjusted by frequency conversion device.

4. Main electronic components are all from famous international enterprises, such as OMRON, Mitsubishi.

Technical parameters:

Model	RCGFB18-12-18-6	RCGFB24-18-24-8	RCGFB32-24-32-12	RCGFB40-32-40-12
Production Capacity:500ml(B/h)	5000	8000	12000	15000
Suitable Bottle Types(mm):	Round or square square shaped bottle
PET Bottle Dimension: (mm)	Bottle diameter:50-110 Height :150-330mm
Suitable Cap Standard:	plastic screw Cap
Filling Precision	within ±5mm
Filling Pressure(Mpa)	0.15-0.35	0.15-0.35	0.15-0.35	0.15-0.35
Rinsing Precision:(Mpa)	0.2-0.25	0.2-0.25	0.2-0.25	0.2-0.25
Installed Capacity:(L)	4.3	6.5	10	12
Overall Size(mm)(L×W×H)	3170×2070×2400	4070×2350×2400	5100×2600×2400	6250×3050×2400
Total Weight: (kg)	4000	5000	6000	7000
