Bottle filling equipment
It is used for packing the pure water, mineral water, etc. in PET bottles. we can supply the whole production line.
Characteristics:
1. The washing, filling and capping 3 kinds of jobs will befinished just by this one machine.
2. It is very convenient to change diverse sizesof bottles by means of advanced bottle conveying technology--bottleneck clampingand bottle suspending technology.
3. Advanced programmable PLC is equipped to controlthe main machine. Main electronic
components are all from famous internationalenterprises.
4. All spare parts that may touch with water are made from high-qualitystainless steel.
Main Technical Specifications
Model: |
CGF16/12/6 |
CGF18/18/6 |
CGF24/24/8 |
CGF32/32/12 |
CGF40/40/12 |
CGF48/48/12 |
Production Capacity:500ml(B/h) |
4000 |
6000 |
10000 |
14000 |
17000 |
20000 |
Suitable Bottle Standard:(mm) |
150-300 |
150-340 |
150-340 |
150-340 |
150-340 |
150-340 |
Suitable Cap Standard:(mm) |
φ50-φ110 |
|||||
Filling Pressure:(Mpa) |
0.2-0.3 |
|||||
Filling Model: |
||||||
Installed Capacity:(L) |
3.13 |
3.84 |
3.84 |
5.6 |
6.3 |
7.3 |
Filling Temperature: |
Room Temperature |
Room Temperature |
Room Temperature |
Room Temperature |
Room Temperature |
Room Temperature |
Overall SizeL×W×H(mm) |
2400×1670 ×2350 |
2470×1970 ×2350 |
2865×2170 ×2350 |
3700×2570 ×2350 |
3800×2950 ×2400 |
4500×3400 ×2400 |
Total Weight:(kg) |
2500 |
3000 |
4000 |
5000 |
6000 |
7000 |
About Factory
15 years’ experience in filling line machinery; 12 years gold supplier on .
About Quality
Brand-new equipments with latest design and suitable material made,
About After Sale Service
1 year warranty period and life time technical support.
