5 gallon filling water plant
Characteristics: The parts touching with water adopt high-quality stainless stee. The cylinder gear runs smoothly and the fixed position is correct. It adopts inserting-type washing technology to remove washing blind angle.
Main Technical Parameters:
Machine |
Model |
QGF-120 |
QGF-240 |
QGF-300 |
QGF-400 |
QGF-600 |
|
Capacity (b/h) |
120 |
240 |
360 |
480 |
600 |
|
Filling head |
1 |
2 |
3 |
4 |
5 |
|
|
Overall size (mm) |
3700*1600*1800 |
4000*1500*1800 |
4000*1580*1800 |
4000*1580*1800 |
5000*1850*1900 |
|
Power |
Main machine (kw) |
3.8 |
6.8 |
8.8 |
11 |
11 |
Heating(kw) |
|
9 |
10 |
12 |
12 |
|
Compressed air |
Air pressure |
0.6 |
0.6 |
0.6 |
0.6 |
0.6 |
Air consumption |
0.2 |
0.2 |
0.3 |
0.4 |
0.5 |
|
Lye |
Inside rinse |
20s*2 |
20s*2 |
20s*2 |
20s*2 |
20s*2 |
Outside spray |
20s*1 |
20s*1 |
20s*1 |
20s*1 |
20s*1 |
|
Circle water |
Inside rinse |
20s*2 |
20s*2 |
20s*2 |
20s*2 |
20s*2 |
Outside spray |
20s*1 |
20s*1 |
20s*1 |
20s*1 |
20s*1 |
|
Sterilizing water |
Inside rinse |
20s*2 |
20s*2 |
20s*2 |
20s*2 |
20s*2 |
Outside spray |
20s*1 |
20s*1 |
20s*1 |
20s*1 |
20s*1 |
|
Pure water |
Inside rinse |
20s*2 |
20s*2 |
20s*2 |
20s*2 |
20s*2 |
Outside spray |
20s*1 |
20s*1 |
20s*1 |
20s*1 |
20s*1 |
|
|
Pure water rinsing consumption |
600 |
1000 |
1500 |
2000 |
2500 |
|
About Factory
15years’ experience in filling line machinery; 9 years gold supplier on .
About Quality
brand-new equipments with latest design and suitable material made,
About After Sale Service
One year warranty period and life time technical support.
