Specifications
Bottle packaging machine1. pet bottle , glass bottle
2. Water/juice/soft drink/liquor
3. SS304/316
Water/juice/soft drink/liquor bottle packaging machine
water/juice/soft drink bottle packing line
reliable machines,high quality
advanced technology
- This series of Complete bottle packaging machine are applied to the production of pure water, mineral water, with optional capacity from 2,000 to 20,000BPH. The washing, filling and capping will be finished just by this one machine.
- This bottle packaging machine has a compact structure, perfect control system, easy to operate and highly automated.
- The parts contact with product is made of quality SUS, anti-corrosive, and easy to clean.
- By adopting high speed filling valve, the liquid level is precise and no waste. That guarantees the demand of filling technology.
- Equipped with perfect clean management system to ensure the bottle clean.
- Only by changing the star-wheel, can realize to fill the changed bottle shape.
Technical parameter
Production capacity: 2,000-20,000B/H (500ml)
Filling precision: ≤±5mm (liquid level)
Filling pressure: <0.4Mpa
Polyester bottle specification: bottle diameter:φ50-φ120mm
Bottle height: 150-320mm
Suitable cap type: plastic screw cap
Water pressure of washing bottle: 0.18-0.25Mpa
Water consumption for washing bottle: 800Kg/H
Spraying position: 6
Dripping bottle position: 3.5
Gas source pressure: 0.4Mpa
Gas consumption: 0.4m3/Min
Total power: 3Kw
Overall dimension: 2100×1800×2200mm.
Details of each part
Washer
l. The rotary wheel is a fully stainless steel welded structure.
2. The machine applies unique overturning bottle clamp, which is an innovation of our company. This bottle clamp grips bottle at neck position, avoiding bottle mouth thread contamination caused by rubber gripper block of a traditional bottle clamp. Made of SUS304 stainless steel, this bottle clamp is hygienic and durable.
3. The high efficiency atomizing spay nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and also saves rinsing water.
4. The rinser is driven by driving system positioned inside machine frame via gear transmission.
5. Made of stainless steel of superior quality.
6. Equipped with bottle jam protection device.
Filler
l. Rotary wheel fully made of stainless steel SUS 304.
2. Gravity filling method.
3. Filling valves are made of SUS316L.
4. Filling valves are reasonably structured with accurate filling.
5. Bottles go up and down in the function of cam through elevator, to process filling with contact to bottle-mouth.
6. Level of cylinder is controlled with float-ball.
7. Filler is driven through gears inside the machine frame.
8. Link-wheels in rinser, filler and capper are transported in ringed support of bottle-neck.
Capper
Capper is the machine with highest precision, influence very much with the stability and reliability of the filling monoblock. Our capper features as follows:
l. The equipment is designed with the support of experts from school of engineering and mechanical in Shanghai Jiao Tong University, and uses the technology of Arol from Italy, most advance technology in the world, developed with the experience of asepsis filling machine.
2. Cap distributing chute is equipped with reverse cap stop and reverse cap pick-out mechanism.
3. Cap distributing chute is equipped with a photocell switch to stop the capper when there is no cap inside the chute.
4. The capper is equipped with inlet bottle detection switch.
5. Centrifugal way of cap arranging is adopted to reduce damage of caps.
6. A cap inspecting system is applied to control on-off of elevator.
