Digital Timer TH-190 Timer Digital 12v

Digital Timer TH-190 Timer Digital 12v thumbnail-1
Digital Timer TH-190 Timer Digital 12v thumbnail-2
Digital Timer TH-190 Timer Digital 12v thumbnail-3
Digital Timer TH-190 Timer Digital 12v thumbnail-4
Digital Timer TH-190 Timer Digital 12v thumbnail-5
Digital Timer TH-190 Timer Digital 12v thumbnail-6
Digital Timer TH-190 Timer Digital 12v photo-1
Digital Timer TH-190 Timer Digital 12v photo-2
Digital Timer TH-190 Timer Digital 12v photo-3
Digital Timer TH-190 Timer Digital 12v photo-4
Digital Timer TH-190 Timer Digital 12v photo-5
Digital Timer TH-190 Timer Digital 12v photo-6
US$ 5 - 6 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
TITCHA
Model Number:
TH-190
Contact Supplier Request Quote Chat Now
Wenzhou Giant Electrical Appliances Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name TITCHA
Model Number TH-190
Theory Other, timer
Usage Other, digital timer
Size Miniature
Protect Feature Epoxy
Contact Load Low Power

Application of Digital timer TH-190 TH-190:

It can be directly commected,with small size,low power consumption,big operating temperature range,anti-interference ability an so on.There are functions such adjust the time and countdown.



Technical Parameter:

Rated Voltage AC220V 50/60Hz
Power range 180-250V
Resistive load switching capacity 16A
Contact

1NO/1NC
Power consumption <2VA
Dispaly LCD
Swotching frequency 16 NO/16NC
Min.switching time 1min
Timing range 1MIN-168HOUR
Timing error

<±0.5s/d
Electrial life 100000 times(Raed load)
Mechanical life 10000000 times



 Other popular products:



general purpose relay,Omron relay,relay MY4,LY2,MY2,RH2B-U,55.12

time relay, timer,time switch,time controller, countdown timer ST3P,ST2P,H3Y,H3CR-A8

timer,digital timer,weekly timer, DH-24S,TH-192,TH-190

miniature electromagnetic relay,miniature relay,T73,4123,4078

phase failure relay,NPR, open phase protector TPNF



Application:

general purpose relay omron relay HH54P (MY4)

Features:

Size mm : 20.5×27×33.4
Terminal layout:4Z
Contact capacity:3A 220VAC/3A 28VDC
Contact resistance:≤50mΩ
Insulation resistance:≥100MΩ
Dielectric strength:BOC 1000VAC/BCC 1500VAC

Main technical parameters:

Model
MY2
MY3
MY4
HH52P
Coil rated voltage
DC 6 to 110V
DC 6 to 110V
DC 6 to 110V
DC 6 to 110V
AC 6 to 220V
AC 6 to 220V
AC 6 to 220V
AC 6 to 220V
Coil rated power
DC≤0.9W
DC≤0.9W
DC≤0.9W
DC≤0.9W
AC≤1.2VA
AC≤1.2VA
AC≤1.2VA
AC≤1.2VA
Electrical Life
105OPS
105OPS
105OPS
105OPS
Mechanical life
107OPS
107OPS
107OPS
107OPS
Operating temperature
-40~70
-40~70
-40~70
-40~70
Weight
≤32g
≤32g
≤32g
≤32g
Mounting methods
Printed Circuit board
Flange,outlet
Printed Circuit board
Flange,outlet
Printed Circuit board
Flange,outlet
Printed Circuit board
Flange,outlet



Time relay ST3P

Voltage:AC12-220V 50/60Hz DC12V-24V
Comtact:Time 2 SPDT   ST3PC:Time 1 SPDT lnst.1SPDT
Operation:Time 1 SPDT   ST3PC: On-delay with ntact
Timing Range:A: 0.05-0.5S/5S/30S/3M
B: 0.1-1S/10S/60S/6M
D: 1-10S/10S/100S/10M/60M
E: 5-60S/10M/60M/6H
F: 0.25-2M/20M/2H/12H
G: 0.5-4M/40M/4H/24H
