Product image
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Product data
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
1,UT310 series handheld vibration meter is designed with acceleration sensor and digital measurement circuit. It’s mainly used in measuring the vibration of mechanical equipment, velocity, and acceleration. The measured data are compared with the national, international, corporate, machinery working standard to decide the condition (good, note or dangerous, etc.) of the machine(fan, pump, compressor, motor, etc.).
2,Can be widely used in mechanical manufacturing, electric power, petroleum chemical industry, metallurgy, aerospace and other fields. It’s the ideal measurement tool for purchasing inspection, operation monitoring and maintenance for the rotating machinery equipment.
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Product attribute
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
| Specifications | Range | Best Accuracy |
| Model | UT315 | |
| Acceleration(Freq.) | 0.1~199.9m/s2 (10Hz ~ 10KHz) | ±(5%+2) |
| Velocity(Freq.) | 0.01~19.99cm/s(10Hz ~ 1KHz) | ±(5%+2) |
| Displacement(Freq.) | 0.001~1.999mm(10Hz ~ 500Hz) | ±(5%+2) |
| Features | ||
| Display Count | 1999 | |
| Auto Power Off | √ | |
| Low Battery Indication | ≤7.0V | √ |
| Data Hold | √ | |
| MAX Mode | √ | |
| Data Logging | 1999 | |
| Data Recall | √ | |
| USB Interface | √ | |
| LCD Backlight | √ | |
| General Characteristic | ||
| Power | 9V Alkaline Battery(6LF22) | |
| LCD Size | 57mm X 37mm | |
| Product Color | Red and Grey | |
| Product Net Weight | 365g | |
| Product Size | 166mm X 80mm X 30mm | |
| Standard Accessories | Battery,USB Interface Cable,PC Software CD,Magnet Pedestal,Long Probe,Short Probe,Connection Screw,Carrying Bag | |
| Standard Individual Packing | Gift Box, English Manual | |
| Standard Quantity Per Carton | 40 PCs | |
| Standard Carton Measurement | 530mm X 420mm X 365mm (0.081 CBM Per Standard Carton) | |
| Standard Carton Gross Weight | 24 Kg | |
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
