GT05 Rotated Sealant Spreading Table
US$ 2,500 - 6,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Machine Type:
Glass Coating Machine
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Solar Glass Washing MachineUS$ 5,000 - 8,000MOQ: 1 Set -
Vertical Glass Washer Machine for Double Glazed GlassUS$ 5,000 - 8,000MOQ: 1 Set
-
Air Filler Machine for Double Glazing GlassUS$ 220 - 560MOQ: 1 Set
-
Glass Gas Charging Machine for Double Glazing GlassUS$ 220 - 560MOQ: 1 Set
-
Revolving Sealant-spreading TableUS$ 360 - 560MOQ: 1 Set
Condition
New
Machine Type
Glass Coating Machine
Place of Origin
Shandong, China
Brand Name
Bohman
Model Number
GT05
Voltage
380V 50Hz
Certification
CE
Warranty
one year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Rotated Sealant Spreading Table1.Insulating glass machine
bined hydro-pneumatic drive
Rotated Sealant Spreading Table
1. Contact Information
Alice Meng
86-13953166178
bohman_alice-----yahoo----cn
2. Equipment Features
1.This machine is a special equipment for extruding two-component polysulfidesealant and two-component copper silicon for manufacturing aluminum-frame type insulated glass.
2.Combined hydro-pneumatic drive and noncontact electrical control system is adopted for the main pump and auxiliary pump.
3.It features sensitive switchover,continuous stable sealant extrusion,high production efficiency,easy operation and maintenance.
4.It is an important equipment to manufacture aluminum-frame type insulated glass and curtain wall glass.
3. Main technical parameters
| Model | GT05 |
| Mix ratio | 6:1-14:1 |
| Charging barrel | 200L |
| Curing agent barrel | 20L |
| Max.air consumption | 0.5cubic meter/min |
| Squeeze pressure | 20Mpa |
| Air pressure | 0.5-0.8Mpa |
| Total weight | 680kg |
| Outside dimension | 1250*1100*2500mm |
