Specifications
Lock Hole Slot Machine for Aluminum & PVC Win-doors1. used for processing handles in three hole
2. the slots
Lock Hole Slot Machine for Aluminum & PVC Win-doors
1. Contact Information
2.Equipment Features
1. Used for milling holes and grooves of all types of lock-installation for aluminum doors and windows
2. It is made of the horizontal three-holes drill and vertical copy-routing mill
3. The vertical location of the three-holes drill can be ajusted
4. Colum-oriented guide is installed for the vertical movement of the three-holes drill head, which ensured that three holes is parallel to the bottom
3. Main Specification and Technical Parameter
Power Supply |
380V 50Hz |
Motor Power |
1.85Kw |
Air Consuption |
3L/min |
Operation Air Pressure |
0.5~0.8Mpa |
Main Shaft Rotary Speed |
11200r/min 910r/min |
Blade Specification |
Φ5mm Φ8mm |
Copy-routing Range |
90mmX290mm |
Contour Dimension |
4050X1130X1500mm |
4. Part Pictures
