Help CenterWDYY Hydraulic Extruding Press
Related Products
Specifications
This machine has higher press, easy to operate,widely usege,and stable workingWDYY Hydraulic Extruder press ,that is a specific installation, is slantwise charged with the material and extruders products verically based on the philosophy of plasic extruding. Fited on vacuum pumps and different moulds, the extruder may spueeze out the honeycomb,like ceramic wares where there are solid,hollow and micro pores,or it may produce other raw materials and different sizes of products.
Model type |
WDYY80 |
WDYY68 |
WDYY40 |
WDYY25 |
|
Main cylinder pressure |
800KN(80t) |
680KN(68t) |
400KN(40t) |
250KN(25t) |
|
Main cylinder stroke |
660mm |
500mm |
400mm |
350mm |
|
Feed barrel dia&length(mm) |
φ250*550 |
φ200*500 |
φ250*500 |
φ250*350 |
|
Main cylinder rated prssure |
16Mpa |
20Mpa |
20Mpa |
20Mpa |
|
Positioning cylinder rated pressure |
5Mpa |
20Mpa |
5Mpa |
5Mpa |
|
Motor |
11KW |
11KW |
7.5KW |
5.5KW |
|
Vacuum pump |
2XA-4A |
||||
Oil tank capcity |
200L |
||||
Feed barrelcomer |
0~65 |
||||
Extruder adjustable angle |
0~90 |
||||
Oil for hydraulic unit |
Antiwear oil 46# |
||||
Main cylinder speed |
Return speed |
≤1.5m/min |
|||
Stable extrusion speed |
0.1-0.7m/min |
||||
Send Inquiry to This Supplier
