Customized Size Round RFID Tag Inlays 13.56MHz (HF)
- Nanning
- T/T Credit Card
You May Like
-
13.56mhz Rfid Library Tag Classic Item for Labels
-
Icode 2 13.56mhz Rfid hf Label Inlay Product
-
Rfid Circular Tag Inlay With 512 Bit RFID Custom Inlay HF 13.56Mhz Small Sizes RFID ISO14443A
-
FM08 hf 13.56 Mhz Rfid Inlay for Ticket Label
-
Fm08 hf Rfid Inlay Production for Nfc Labelling
-
Passive UHF Rfid Dry Inlay in Alien 9630
Product Details
| Place of Origin | Guangxi, China | Brand Name | xgs | |
| Model Number | N03303351H |
Product Description
The Advantage of Rfid Round Inlay :
- Wide frequency band for global use.
- High soulution for Labels of all kinds for Library management(small DCD/CD tags), Access control ,Ticketing. Anti-fake solution .etc
- HF rfid inlay has steady reading distance. Stable performance.
Technical Datasheet:
| Item name | Customized size Round RFID tag Inlays 13.56MHz (HF) |
Model Number | N03303351H |
| Standard | ISO/IEC 14443A |
| Frequency | HF 13.56 MHz |
| Inlay size | 33mm |
| Antenna Size(O.D) | 33mm aluminum etching antenna |
| Inlay Material | Antenna: AL,30μm±3μm |
Chip : Silicon,150μm±10μm | |
Substrate : PET,38μm±5μm | |
| Standard Pitch | 59.5mm |
| Material | AL-etching antenna, PET substrate |
| Chip | Ultralight MF0 |
| User Memory | 512 bit |
| Label Dimension | can be customized |
| Reading Distance |
3-10cm(reader dependent or antenna design)
|
| Work Temperature | 20 to 80°c |
| Store Temperature | -40°C to + 65°C |
| R/W Cycles | up to100,000 cycles times |
| Data Transfer Rate: | 106Kbit/s |
| Operating Mode | Passive(battery free) |
Dry Inlay Max Units Per Roll | 5000 pcs |
Wet Inlay Max Units Per Roll | 5000 pcs |
| PESD | Human Body : 1.5KV |
| Charged Device:1.5KV | |
Benefits |
Designed for use Access control,Library management,Ticketing or other normally challenging for RFID.
|
Samples | Depending on customer requirements |
General Application Description
|
Rfid Round Inlay can be used to produce RFID label, smart card, and other RFID tags. Rfid Round Inlay has short or medium read range, it features stable reading performance and less environmental influences, perfectly suited for applications such as access control, library management, ticketing, contact-less payment, etc.
|
Detail pictures for you :
Typical applications about Rfid Round Inlay Inlay RFID Custom Inlay HF 13.56Mhz Small Sizes RFID ISO14443A :
See Rfid Round Inlay was Chip-on-books to tracking their Books in libraries :

See RFID inlay was converted into works for access control :
After-sale service and guarantee
1.We provide technical support for your system integration, RFID labels and tags printing, RFID chips encoding, RFID reader installation guide, etc.
2. Return policy:
-Any products found damaged or unworkable, we will check and replace those products.If customers want to return the items received, you must concact us within 7 days after receipt of your order.
-Customers should pay the additional shipping fees incurred and the products returned should be kept in their original conditions.
Nanning Xingeshan Tech is manufacturer of RFID inlay, RFID label, rfid tags, and rfid label. and rfid readers
Our production facilities are imported from Germany Muehlbauer, which means high level quality in RFID field.
Our Advantages:
1.High quality insurance : World well know production lines: Germany Muhlbauer TAL5000 bonding line
and CL15000 coverting line.
2. Fastest delivery time : 5000 pcs/hour and 3,000,000 pcs per month output .
3. Experienced designing and producing RFID tags (inlay, label, other tags).

Germany Muhlbauer TAL5000 flip-chip production line for dry inlay:
Germany Muhlbauer CL15000 convertin g line for labels and wet inlay:
Did you find what you are looking for ?if not,Don't worry,try to contact us ,We can design and develop RFID tags and RFID readers in different sizes and different shapes for your different requirements.
For more info about RFID products please kindly contact or mail to us, our sales will contact you as soon as possible.
