NUT USING RANGE SHEET
SIZE INCH (mm) |
STANDARD JAW OPENING WIDTH |
OUR WIDER MAXIMUM JAW OPENING NOT LESS THAN (mm) |
USING RANGE FOR |
|
METRIC HEXAGON NUT'S SIZE |
SAE HEXAGON NUT'S SIZE |
|||
AW-4" (100mm) |
13mm |
17mm |
M1~M10 |
W1/8~W3/8 |
AW-6" (150mm) |
20mm |
23.9mm |
M1~M16 |
W1/8~W1/2 |
AW-8" (200mm) |
24mm |
28.6mm |
M1~M18 |
W1/8~W5/8 |
AW-10" (250mm) |
29mm |
32.8mm |
M1~M22 |
W1/8~W3/4 |
AW-12" (300mm) |
34mm |
38.1mm |
M1~M24 |
W1/8~W7/8 |
AW-15" (375mm) |
43mm |
50mm |
M1~M33 |
W1/8~W1-1/4 |
AW-18" (450mm) |
53mm |
60mm |
M1~M39 |
W1/8~W1-1/2 |
AW-24" (600mm) |
62mm |
70mm |
M1~M45 |
W1/8~W1-3/4 |
Chrome vanadium, exceeding international standards as ISO 6787-1982, ASME B.107.8M-1996, BS 6333-1995, Din 3117-1988, JIS B4604-1976 Heavy Duty, SABS, 1211-1984 Heavy Duty, CNS.
Noiseless – Low rattle
1. Super strong, precise in-house manufactured knurl with subtle chamfering on both ends
enables easier turning with more safety – no sharp edges to hurt fingers. Positive jaw engagement; due to exact manufacturing tolerances, there is no jaw movement in whatever angle the wrench is held at.
2. With exact tolerance, Wider Jaw Opening increases the size range of fasteners that can be turned giving greater versatility and value for money.
3. Non-Protruding movable jaw end & super thin head allows easier access and use in tight
spaces; especially useful for example “under the hood/bonnet” of automotive engine
application.
4. The horizontally mechanical polishing creates a delicate surface with no irregular curves – a
professional looking finish.
5. On our ergonomically designed handle, the grasp part is 60% thicker than a regular wrench,
providing the tool user with a more functional and comfortable grip, especially at high loads.
-
A smaller angle 15wrench aligns the wrench with the nut in a manner that offers speed,
precision, ergonomic comfort and provides greater leverage distance thus reducing hand &
arm fatigue. It makes the hardest work easy.
-
The special design of the head means that when the wrench is laid flat, the knurl is held off the
surface thus avoiding accidental engagement and change in the opening width of jaw.
-
Super Positive jaw/knurl engagement fixes the opening making it unlikely to change between uses, unlike a standard wrench where constant adjustment is required.
| Item NO. | PCS/Inner CTN | PCS/Outer CTN | N.W. | G.W. | Cuff |
| AW-06" | 12.0 | 10.0 | 14.4 | 15.6 | 0.6 |
| AW-08" | 12.0 | 6.0 | 17.3 | 18.5 | 0.6 |
| AW-10" | 12.0 | 3.0 | 14.4 | 15.1 | 0.5 |
| AW-12" | 6.0 | 4.0 | 15.8 | 16.8 | 0.5 |
| AW-15" | 4.0 | 4.0 | 21.5 | 22.5 | 1.3 |
| AW-18" | 1.0 | 10.0 | 18.7 | 19.5 | 0.9 |
| AW-24" | 1.0 | 6.0 | 20.0 | 21.0 | 0.9 |
