24v dc Inverter Connect With Solar Panel Solar Inverter 4kw 220v
US$ 1 - 20
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
REFWORLD
Model Number:
RW-50
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
REFWORLD
Model Number
RW-50
Type
Other, connecting terminal
24v dc inverter connect with solar panel solar inverter 4kw 220v
| Characteristics of application: | |||||||||||
| JHD series terminal blocks features compact,reasonable structure,beautiful shape ,wide installing filed.It can be installed on TH35 and G32 type rail.When installation,it can be realized by elasticity of material and reasonable structre.The connection of lead can adapt the method of using screw to lift and press lead frame to press and jiont lead.It is not only convenient and compact structure but also does not damage the lead. | |||||||||||
| Feature | Current | Voltage | connecting wire(mm2) | dimension | screw | ||
| Model | single | double | (w*h*t) | regulation | torque | ||
| JHD-1.5 | 17A | 500V | 0.2-2.5 | 0.2-1.5 | 41×42.5×4.2 | m2 | 0.4Nm |
| JHD-2.5 | 24A | 660V | 0.2-4 | 0.2-2.5 | 41×42.5×6.2 | m3 | 0.6Nm |
| JHD-5 | 38A | 600V | 0.6-6 | 0.2-4 | 46×42.5×6.2 | m3 | 0.6Nm |
| JHD-10 | 76A | 690V | 0.5-16 | 0.5-10 | 46×42.5×10.2 | m4 | 1.8Nm |
| JHD-16 | 85A | 726V | 2.5-25 | 4-16 | 53×42.5×12.2 | m4 | 1.8Nm |
| JHD-35 | 140A | 600V | 0.75-35 | 0.75-35 | 62×51×15.2 | m6 | 4Nm |
| JHD-50 | 150A | 1000V | 16-50 | 25-50 | 86.5×70.5×20.2 | m6 | 4Nm |
| JHD-95 | 232A | 1000V | 25-95 | 35-95 | 90×83×25.2 | m8 | 5Nm |
| JHD-4s | 41A | 500V | 0.2-4 | 0.2-4 | 52×61×6.2 | m3 | 0.8Nm |
| JHD-6s | 57A | 400V | 0.5-10 | 0.5-6 | 59×72×12.2 | m4 | 1.8Nm |
