BLR/SA SUCTION LINE ACCUMULATOR

BLR/SA SUCTION LINE ACCUMULATOR thumbnail-1
BLR/SA SUCTION LINE ACCUMULATOR photo-1
US$ 1 - 100 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Condition:
New
Type:
Distillation Equipment
Brand Name:
BLUE
Contact Supplier Request Quote Chat Now
Ningbo Refworld Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Distillation Equipment
Brand Name BLUE

BLR/SA SUCTION LINE ACCUMULATOR

GENERAL DEFINITION

  • Suction line accumulators partially eliminate risk of returning cooling gas into compressor in liquid form.
  • "U" tube design is used to provide maximum cooler flow, and minimum oil trap.
  • It provides excessive cooling of gas in liquid line and quick evaporation of liquid drops coming to liquid trap.
  • The system comprises the following;Long-line systems,Conversion circuit systems,Heating pump and defrost applications. Recommended for liquid coolers.
  • Ensure correctness of In & Out signs on suction line accumulators.

Connection Parts

  • We determined Input and Output connections according to volume of products.
  • ODS connection is used in standard products.
  • Different connection may be used upon request.
  • Please contact us for further details.
  • There is no Safety Valve connection in standard products.
  • Safety Valve connection can be provided upon request.
  • Please contact us for different Safety Valve connections.
 NOTE
  • Our firm manufactures products of any required diameter, length, and properties according to relevant standards.
  • Different colors may be used upon request in number of quantities.
  • Liquid receivers  are manufactured in accordance with  CE 97/23/EC directive.
  •  Please contact us for further details.

DRAWING&PICTURE



 BLR/SA SUCTION LINE ACCUMULATOR



TECHNICAL DATA



MODEL
Connection
(Inch)
Dia A
(Inch)
Dimension(Inch)
Volume
Height
Connection
Height
Distance
H
D
W
(L)
BLR/SA-S05
5/8"
3.15
10.24
1.37
1.38
1.28
BLR/SA-S06
3/4"

12.2
1.37
1.38
1.5
BLR/SA-204
1/2"
4
8.47
1.37
2.12
1.39
BLR/SA-205S
5/8"

8.47
1.37
2.12
1.39
BLR/SA-205
5/8"

10.83
1.37
2.12
1.9
BLR/SA-206
3/4"
5.5
10.24
1.57
3.15
3.5
BLR/SA-207S
7/8"

10.24
1.57
3.15
3.5
BLR/SA-207
7/8"

12.6
1.57
3.15
4.36
BLR/SA-211
1 1/8"
6.5
15.75
1.77
3.15
7.4
BLR/SA-213
1 3/8"

20.87
2.16
3.31
9.9
BLR/SA-215
1 5/8"

22.84
2.16
3.23
10.9
BLR/SA-221
2 1/8"
8.5
28
2.36
5.12
24.2
BLR/SA-225
2 5/8"
10.75
25.6
2.95
6.3
33.4
BLR/SA-231
3 1/8"
12.75
23.62
2.95
7.09
43.19
BLR/SA-231
3 1/8"
12.75
23.62
2.95
7.09
43.19
BLR/SA-16218
2 1/8''
8.62
16.54
3.15
8.09
15
BLR/SA-19218
2 1/8''
8.62
21.57
4.21
8.09
18
BLR/SA-22218
2 1/8''
10.75
19.49
4.72
8.09
21
BLR/SA-36258
2 5/8''
12.81
21.61
6.57
8.09
35
BLR/SA-57318
3 1/8''
15.83
21.61
7.05
8.09
56
BLR/SA-70358
3 5/8''
17.72
21.61
9.06
8.09
70
BLR/SA-80412
4 1/2''
17.72
24.02
3.07
8.09
80
BLR/SA-95514
5 1/4''
17.72
27.95
3.35
8.09
93
