Bi-Flow Liquid Line Filter Drier For Heat Pump

Name: Bi-Flow Liquid Line Filter Drier For Heat Pump
Brand: BLUE
SKU: 107427447

US$ 5 - 20 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

BLUE

Model Number:

BLR/BFK-052

Ningbo Refworld Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name BLUE

Model Number BLR/BFK-052

Type Filter Drier

Application Refrigeration Parts

Certification UL

General description

BLR/BFK is a solid core, bi-directional, liquid line Filter Drier for heat pump applications for use with CFC, HCFC, and HFC refrigerants.

Desiccant Blend: optimized for high water capacity and acid capacity

Features

Corrosion resistant epoxy powder paint finish,Salty test up to 400 hour
Available 5 to 30 cu. in. size
Internal check valves allow flow and filtration in either direction, eliminates need for external check valves Available in sizes from 3 to 75 cubic inches.
High moisture and acid removal capacity
Approved for POE oils
S.S. Filtration: 20 microns
Maximum working pressure: 680 psig
Suitable for R410A

Drawing&Picture

Technical data

MODEL	CONNECTION (Inch)	FLOW CAPACITY TONS @ 1 psi P (For kw,multiply tons by 3.5)			DIMENSIONS(mm)				WT
MODEL	CONNECTION (Inch)	R-22	R-410A	R-407C	A	B	C	D	(Ibs)
BLR/BFK-052	1/4SAE	1.6	1.6	1.6	122.428	76.20	-	66.548	1
BLR/BFK-052S	1/4ODF	2.2	2.2	2.2	112.776		93.726
BLR/BFK-053	3/8SAE	-	-	-	130.302		-
BLR/BFK-053S	3/8ODF	4.0	4.0	3.9	113.792		93.218
BLR/BFK-082	1/4ODF	-	-	-	133.858	97.028	114.808
BLR/BFK-0825S	5/16ODF	-	-	-	127.508		111.252
BLR/BFK-083	3/8SAE	4.5	4.5	4.4	150.876		-
BLR/BFK-083S	3/8ODF	5.1	5.1	5.0	134.366		113.792
BLR/BFK-084	1/2SAE	6.4	6.4	6.3	156.464		-
BLR/BFK-084S	1/2ODF	6.7	6.7	6.6	136.652		111.25
BLR/BFK-085	5/8SAE	-	-	-	168.148		-
BLR/BFK-085S	5/8ODF	8.1	8.1	7.9	142.24		110.49
BLR/BFK-163	3/8 SAE	4.6	4.6	4.5	171.196	117.094	-	80.01	2
BLR/BFK-163S	3/8ODF	5.2	5.2	5.1	154.432		134.112
BLR/BFK-164	1/2SAE	7.7	7.7	7.6	176.784		-
BLR/BFK-164S	1/2ODF	8.1	8.1	7.9	156.718		131.318
BLR/BFK-165	5/8SAE	8.3	8.3	8.1	188.214		-
BLR/BFK-165S	5/8ODF	8.7	8.7	8.5	162.306		130.556
BLR/BFK-167S	7/8ODF	-	-	-	177.546	190.5	139.446	80.01
BLR/BFK-303	3/8 SAE	-	-	-	244.602
BLR/BFK-303S	3/8ODF	5.8	5.8	5.7	227.838				3.75
BLR/BFK-304	1/2SAE	7.6	7.6	7.5	249.936
BLR/BFK-304S	1/2ODF	9.7	9.7	9.5	229.108
BLR/BFK-305	5/8SAE	10.3	10.3	10.1	261.874
BLR/BFK-305S	5/8ODF	14.2	14.2	13.9	236.474
BLR/BFK-306	3/4SAE	-	-	-	269.494
BLR/BFK-306S	3/4ODF	16.0	16.0	15.7	246.888
BLR/BFK-307S	7/8ODF	16.7	16.7	16.4	251.714
BLR/BFK-309S	1-1/8ODF	-	-	-	259.588
