i Inch Rod Ends Bearing XM XF Series Male and Female

i Inch Rod Ends Bearing XM XF Series Male and Female photo-1
US$ 0.1 - 10 MOQ: 50 Pieces
Key Specifications
Get Latest Price
Brand Name:
UMT
Bore Size:
0.3125,
Model Number:
XM-5
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Brand Name UMT
Bore Size 0.3125,
Model Number XM-5
Place of Origin China
Precision Rating ABEC-3

Inch rod ends bearing XM XF series male and female



Model:XM-5 / XF-5


  • Body - Carbon Steel protective coated for corrosion resistance.
  • Race - Alloy steel, heat treated protective coated for corrosion resistance. (Carbon steel with Ptfe liners).
  • Ball - Alloy steel, heat treated, hard chrome plated.
  • All sizes solid shank type.
  • Grease Fitting available for all sizes. Units are supplied without grease fittings. When a grease fitting is required, specify by adding suffix "Z" or "F". Ex.: XM-6Z = Zerk Type Fitting XM-6F = Flush Type Fitting.
  • Load ratings apply only to rod ends without grease fittings. For load ratings with fittings, please consult our engineering department.
  • Studded configuration available upon request. Specify by adding suffix "S". Ex.: XM-8S.
  • Ptfe Liners available upon request. Specify by adding suffix "T". Ex.: XM-8T.



























                            i Inch rod ends bearing XM XF series male and female





Specifications

Thread Type

Right Hand

Thread Configuration

Male

B - Ball Bore

.3125 in

W - Ball Width

.437 in

H - Head Width

.344 in

A - Base to Center

1.938 in

D - Head Diameter

1.000 in

Ball Diameter

.625 in

C - Thread Length

1.250 in

Thread Size

3/8-24

Thread Class

UNF-3A

a - Misalignment Angle Clevis Mounted

12.00 º

Ultimate Radial Static Load Capacity

5323 lb

Approximate Brg. Weight

.112 lb

Options

Stud

Type of Lubrication

None











































































































Packaing:

Each rod end bearing is individually packed with plastic bag in the individually color box, then some boxes packed in one carton box.This guarantees no damage in transport. We use pallet for ocean shipment.



Delivery time:

Shipment will be process in 1-2 days if the item you order are in stock.



Payment:

We usually accept bank transfer, L/C at sight, PayPal, Western Union.

Welcome to inquiry us. Please feel free to send e-mail.
