Black Colour Housing Unit bearing UCP204 Pillow block
USD $0.1 - $100
/ Piece
1 Piece(Min.Order)
- 35000000 Piece / Pieces per Month
- Shenzhen China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
- High Grade Certified Factory Supply Fine Outdoor Optical Laser Machinery
- High Grade Certified Factory Supply Fine Laser Rave Lighting
- High Grade Certified Factory Supply Fine Soldering Iron
- High Grade Certified Factory Supply Fine Plastic Film
- High Grade Certified Factory Supply Colorful Plastic Flower Pots
- High Grade Certified Factory Supply Small Plastic Flower Pots
Product Details
Bore Size: | 30, | Brand Name: | UMT | Model Number: | UCP 204 |
Place of Origin: | Guangdong, China |
Product Description
Pillow Block Bearing UCP 204 | |
Quality Standard: | ISO9001:2008 quality management system, TS16949 |
Specification | UCP 204 |
Brand Name: UMT | |
Size: 45*108*49.2mm | |
Net weight: 3.4kgs | |
Seals Type: Rubber seals | |
Number of Row: Single Row | |
Material: Chrome steel, Stainless steel | |
Clearance: C3 | |
Noise Level:Z2 | |
Cage: Brass, Steel, Nylon | |
Features: | 1) Precision: ABEC-1(P0), ABEC-3(P6), ABEC-5(P5), ABEC-7(P4) |
2) Noise level: Z1, Z2, Z3, Z4 | |
3) Vibration Level: V1, V2, V3, V4 | |
4) Clearance: C2, C3, C4, C5 | |
5) Hardness: 59-63 HRC | |
6) Greese: As your requirement, such as SRL, PS2, Alvania R12 and so on. | |
Packing | 1.Industrial packing: plastic tube |
2.Commercial packing: small box then into standard carton | |
3.As per customer's requirement | |
Payment | T/T, L/C, Western Union, MoneyGram, Paypal, D/A |
Delivery time | About 2 to 7 working days after confirmed order |
Services | Warranty time: 1 year |
Samples available: Yes | |
Free technical support and after-sales service |
Pillow Block Bearing / Insert Bearing Catalog
Bearing Unit No. | Shaft Dia d(mm) | Dimensions (mm) | Bolt Used (mm) | Housing No. | Weight (kg) | |||||||||
h | a | e | b | S2 | S1 | g | w | Bi | n | |||||
UCP201 | 12 | 30.2 | 127 | 96 | 38 | 19 | 13 | 15 | 62 | 31 | 12.7 | M10 | P201 | 0.63 |
UCP202 | 15 | 30.2 | 127 | 96 | 38 | 19 | 13 | 15 | 62 | 31 | 12.7 | M10 | P202 | 0.61 |
UCP203 | 17 | 30.2 | 127 | 96 | 38 | 19 | 13 | 15 | 62 | 31 | 12.7 | M10 | P203 | 0.59 |
UCP204 | 20 | 33.3 | 127 | 96 | 38 | 19 | 13 | 15 | 65 | 31 | 12.7 | M10 | P204 | 0.59 |
UCP205 | 25 | 36.5 | 140 | 105 | 38 | 19 | 13 | 16 | 70 | 34 | 14.3 | M10 | P205 | 0.7 |
UCP206 | 30 | 42.9 | 165 | 121 | 48 | 21 | 17 | 18 | 83 | 38.1 | 15.9 | M14 | P206 | 1.1 |
UCP207 | 35 | 47.6 | 167 | 126 | 48 | 21 | 17 | 19 | 92 | 42.9 | 17.5 | M14 | P207 | 1.35 |
UCP208 | 40 | 49.2 | 184 | 136 | 54 | 21 | 17 | 19 | 98 | 49.2 | 19 | M14 | P208 | 1.78 |
UCP209 | 45 | 54 | 190 | 146 | 54 | 21 | 17 | 20 | 106 | 49.2 | 19 | M14 | P209 | 1.81 |
UCP210 | 50 | 57.2 | 206 | 159 | 60 | 25 | 20 | 22 | 112 | 51.6 | 19 | M16 | P210 | 2.53 |
UCP211 | 55 | 63.5 | 219 | 171 | 60 | 25 | 20 | 22 | 126 | 55.6 | 22.2 | M16 | P211 | 2.86 |
UCP212 | 60 | 69.8 | 241 | 184 | 70 | 25 | 20 | 25 | 137 | 65.1 | 25.4 | M16 | P212 | 4.41 |
UCP213 | 65 | 76.2 | 265 | 203 | 70 | 29 | 25 | 27 | 150 | 65.1 | 25.4 | M20 | P213 | 4.96 |
UCP214 | 70 | 79.4 | 266 | 210 | 72 | 31 | 25 | 27 | 156 | 74.6 | 30.2 | M20 | P214 | 5.61 |
UCP215 | 75 | 82.6 | 275 | 217 | 74 | 31 | 25 | 28 | 163 | 77.8 | 33.3 | M20 | P215 | 6.22 |
UCP216 | 80 | 88.9 | 292 | 232 | 78 | 31 | 25 | 30 | 175 | 82.6 | 33.3 | M20 | P216 | 7.63 |
UCP217 | 85 | 95.2 | 310 | 247 | 83 | 31 | 25 | 32 | 187 | 85.7 | 34.1 | M20 | P217 | 8.8 |
UCP218 | 90 | 102 | 327 | 262 | 88 | 33 | 27 | 34 | 200 | 96 | 39.7 | M20 | P218 | 11.4 |
Pillow Block Bearing Insert bearing UCP bearings
Pillow Block Bearing Insert bearing UCP bearings
Pillow Block Bearing Insert bearing UCP bearings
