Home > Construction & Decoration > Fence > Security Fence > High Sensitivity Through Type X-ray Baggage Scanner Equipment XST-6550
High Sensitivity Through Type X-ray Baggage Scanner Equipment XST-6550
US$ 20,000 - 21,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Security King
Model Number:
XST-6550
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN CHINA
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
X-ray Equipment Through Type Securitybaggage Scanner (XST-SF6550)US$ 20,000 - 21,000MOQ: 1 Set -
Through Type Security X-ray Baggage Scanner Equipment (XST-SF6550)US$ 20,000 - 21,000MOQ: 1 Set
-
X-ray Baggage and Luggage Inspection Scanner for Train StationUS$ 18,000 - 20,000MOQ: 1 Piece
-
Handheld Needle Metal Detector XST-N02NegotiableMOQ: 10 Pieces
-
Table Needle Metal Detector XST-N01NegotiableMOQ: 10 Pieces
Place of Origin
Guangdong, China
Brand Name
Security King
Model Number
XST-6550
Specifications
Security X-ray Baggage Scannerunds & light alarm
2.Network interface
3.Safety ray
4.Turn off by a key control
High Sensitivity Through type X-ray baggage scanner equipment
XST-6550
FEATURE
- Alarm by sounds+light Alarm by sounds and light when conform to condition.
- Network interface Could be connect local area network and support multi-terminal check baggage at same times
- Safety ray Transmit ray under automatic control, avoids the miss.
- Turn off by a key control Turn off the machine only need one step revolves the key. The equipment automatic security close-down, does not need complex many steps, is simpler.
- Eagle-eye Could be expediently observing enlargement area.
- Estimate malfunction by self Automatic estimate malfunction and prompt message, helpful for the maintenance.
TECHNICAL DATA
| Tunnel Size | 650(W)×500(H)mm |
| Conveyor Speed | 0.2 m/s |
| Conveyor Max Load | 170 kg |
| Single inspection dosage | < 1.5µGy |
| Wire Resolution | 0.101 mm metal line |
| SPATIAL RESOLUTION LEVEL | 1.0 MM DIAMETER |
| VERTICAL | 1.0 MM DIAMETER |
| PENETRATE RESOLUTION | 0.254 MM DIAMETER |
| Steel Penetration | 34MM armor plate |
| Film Safety | For ISO 1600 |
| Maximum leakage radiation | < 0.05µGY/H |
X-RAY GENERATOR
| Orientation | Vertically Upward |
| Tube Current | 0.4~1.2MA(adjustable) |
| Anode Voltage | 100~160 KV(adjustable) |
| Angle | 60° |
| Generator cooling/working periods | Sealed oil bath with forced air/100% |
OPERATING ENVIRONMENT
| Storage Temperature | -20ºC to 60ºC |
| Operating Temperature | 0ºC to 45ºC |
| Relative Humidity | 20 to 95% non-condensing |
| System Power | 220 VAC (±10%) 50±3HZ |
| Power wastage | 1.0KW (Max) |
| Noise | <65DB |
