X-ray Equipment Through Type Securitybaggage Scanner (XST-SF6550)

X-ray Equipment Through Type Securitybaggage Scanner (XST-SF6550) thumbnail-1
X-ray Equipment Through Type Securitybaggage Scanner (XST-SF6550) photo-1
US$ 20,000 - 21,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Laser Type:
Diode
Place of Origin:
Guangdong, China
Brand Name:
Security King
Contact Supplier Request Quote Chat Now
Shenzhen XinSaiTong Technology Company Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN CHINA
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Laser Type Diode
Place of Origin Guangdong, China
Brand Name Security King
Model Number XST-SF6550

Specifications

Security Baggage Scanner X-ray Equipment
unds & light alarm
2.Network interface
3.Safety ray
4.Turn off by a key control

X-ray Equipment Through type security baggage scanner  (XST-SF6550)



FEATURE

  1. Alarm by sounds+light   Alarm by sounds and light when conform to condition.
  2. Network interface  Could be connect local area network and support multi-terminal check baggage at same times
  3. Safety ray   Transmit ray under automatic control, avoids the miss.
  4. Turn off by a key control   Turn off the machine only need one step  revolves the key. The equipment automatic security close-down, does not need complex many steps, is simpler.
  5. Eagle-eye    Could be expediently observing enlargement area.
  6. Estimate malfunction by self   Automatic estimate malfunction and prompt message, helpful for the maintenance.

TECHNICAL DATA

Tunnel Size 650(W)×500(H)mm
Conveyor Speed  0.2 m/s
Conveyor Max Load 170 kg
Single inspection dosage < 1.5µGy
Wire Resolution 0.101 mm metal line
SPATIAL RESOLUTION    LEVEL   1.0 MM DIAMETER
VERTICAL  1.0 MM DIAMETER
PENETRATE RESOLUTION 0.254 MM DIAMETER
Steel Penetration 34MM armor plate
Film Safety For ISO 1600
Maximum leakage radiation <  0.05µGY/H



X-RAY GENERATOR

Orientation Vertically Upward
Tube Current 0.4~1.2MA(adjustable)
Anode Voltage  100~160 KV(adjustable)
Angle  60°
Generator cooling/working periods Sealed oil bath with forced air/100%



OPERATING ENVIRONMENT

 Storage Temperature  -20ºC to 60ºC
Operating Temperature  0ºC to 45ºC
Relative Humidity 20 to 95% non-condensing
System Power   220 VAC (±10%) 50±3HZ
Power wastage 1.0KW (Max)
Noise  <65DB





X-ray Equipment Through type securitybaggage scanner (XST-SF6550)
